ABB 2CPX033021R9999 CT Meter Panel Enclosure IP2XC

Fully assembled CT meter panel module with IP2XC protection and EN 61439-1 compliance minimizes on-site wiring errors and speeds up commissioning in distribution panels. By delivering a ready-to-install meter cabinet, it cuts installation time and lowers risk during energization, enabling quicker project turnover in manufacturing plants and utility substations. Power path integrity is ensured by Cu busbars 12 x 5 mm and a TN-S earthing system, with N+PE connections rated for 95 qmm. This robust configuration reduces contact resistance and improves fault handling, delivering consistent metering accuracy across load profiles. With 72 DIN place units and a compact 900 × 250 × 160 mm footprint, the panel supports scalable metering and protection layouts within tight cabinet footprints. The 5-pole arrangement, fuse base D01/3-pole sealable, and modular mounting make wiring straightforward and service-friendly, while quick-seal connections simplify field maintenance. RoHS, REACH compliance and CE declarations accompany the unit, simplifying regulatory audits and traceability. The closed cover, 7035 light-grey coating, and durable plastics add protection against dust and impacts in harsh environments. Designed for modularity, the panel accommodates metering transformer sets in a separate housing, keeping the main cabinet uncluttered and compliant with installation standards. Its ETIM and SCIP classifications support procurement and sustainability reporting, while the 900 mm height and 72-DIN format support integration with grid units and other ABB switchgear.
