ABB 2CPX037088R9999 Metering Exchange Board - IP2XC
Part Number: 2CPX037088R9999
Quick Summary
ABB 2CPX037088R9999 Metering Exchange Board is a compact meter panel for internal metering applications. It helps engineers reduce panel footprint and simplify wiring in control cabinets, saving installation time and avoiding costly retrofits. This enclosure carries crucial certifications to support compliant deployments: CE conformity, RoHS compliance, and REACH declarations, along with IP2XC protection for reliable operation in demanding environments. With a 450 x 520 x 160 mm footprint and 144 DIN place units, it scales to support single-story meter arrangements and future metering expansion. In practice, it integrates smoothly with ABB’s line of enclosures and electrical infrastructure, delivering predictable performance, easier maintenance, and lower total cost of ownership for utility-scale and industrial installations.
Product Information
Extended Description
2CPX037088R9999 ABB: Metering exchange board, meter panel, with Metering cross, for the internal use, degree of protection IP2XC, Rated operational voltage 415V AC Hz, rated current 0 A, in RAL 7035, dimensions in mm (H x W x D): 450 x 520 x 160, Number of SG spaces 1, Number of transformer meter spaces 1, Metering wiring, Grid unit 3 GU, Overall height 00, panel width 2, Space units 144, covers out of Plastic, RAL 7035
Rated Operational Voltage
Maximum 415 V
Rated Current (In)
0 A
Model Number
1-story
Number of Meter Cabinets
1
Number of Meter Panels
1
Number of Rows
0
Number of TSG Panels
1
Lower Connection Space
with DIN Rails (Top Hat Rails)
Enclosure Type
Metering exchange board
Enclosure Type of Height
00
Cover Style
Closed
DIN Place Units
144
RAL Number
RAL 7035 - Light Grey
Color
Light grey
RoHS Information
EU Declaration of Conformity Meter panels for half indirect metering
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date
20240903
REACH Declaration
Declaration regarding the REACH – Regulation ABB STRIEBEL & JOHN
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20240902
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Business
Degree of Protection
IP2XC
Width in Number of Modular Spacings
24
Product Net Width
520 mm
Product Net Height
450 mm
Product Net Depth / Length
160 mm
Section Width
2
Product Net Weight
4.805 kg
Package Level 1 Units
pack 1 piece
Package Level 1 Gross Weight
4.997 kg
Declaration of Conformity - CE
EU Declaration of Conformity Meter panels for half indirect metering
Instructions and Manuals
Mounting instruction mounting plate for current transformer
ETIM 8
EC000263 - Meter panel
ETIM 9
EC000263 - Meter panel
eClass
V11.0 : 27142419
Object Classification Code
U
IP2XC protection and closed cover on the ABB 2CPX037088R9999 Metering Exchange Board protect sensitive metering electronics from dust and incidental contact, reducing maintenance cycles and extending cabinet life. This enclosure’s 144 DIN place units maximize meter and CT capacity, enabling scalable metering across single-story or compact multi-meter configurations, which speeds up project delivery and reduces panel footprint. The lower connection space with DIN rails simplifies wiring and mounting of current transformers, cutting installation time and improving reliability in dense electrical infrastructure projects. Compliance features including CE conformity, RoHS, and REACH declarations help you meet regulatory requirements while supporting sustainable procurement and reduced risk of non-compliance penalties. The robust 450 x 520 x 160 mm, 4.805 kg enclosure in RAL 7035 light grey offers a balanced combination of space efficiency and mechanical rigidity for industrial applications. Finally, the WEEE/B2B classification and ETIM/eClass alignment ensure seamless procurement and project scoping in utility and manufacturing sectors.
Get a Quick Quote for a ABB 2CPX037088R9999
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 2CPX037088R9999?
Enquire Now
FAQs
This metering exchange board is designed for 144 DIN place units and lower connection space with DIN rails, enabling straightforward integration with standard current transformers and meter configurations. Its 450 x 520 x 160 mm footprint fits common ABB enclosures and similar industrial cabinet layouts, reducing retrofit complexity and supporting scalable metering layouts.
The enclosure carries IP2XC protection, a closed cover, and robust light-grey RAL 7035 finish, providing dust and incidental contact resistance. Combined with CE, RoHS, and REACH compliance, the unit maintains regulatory conformity and long-term reliability in industrial settings while minimizing corrosion risk and maintenance interrupts.
Yes. The product is CE-conformant, RoHS compliant, and REACH declared with supporting EU declarations. WEEE categorization and B2B procurement alignment (CMRT, ETIM 8/9, eClass) streamline regulatory checks, supplier qualification, and sustainability reporting for industrial projects.
Its 1-story model with 1 meter cabinet/panel, 144 DIN units, and 3 GU grid unit compatibility supports scalable metering for utility and large industrial installations. The DIN-rail mounting, lower connection space, and 450 x 520 x 160 mm footprint enable compact, modular installations with predictable wiring and maintenance workflows.
By reducing installation time through simplified wiring, standardized DIN-rail mounting, and a compact footprint, sites lower labor costs and downtime. Regulatory compliance minimizes risk, while the durable enclosure and ETIM/eClass alignment improve procurement efficiency and asset lifecycle management.
