ABB 2CPX041816R9999 Cable connection module DIN EN 61439-3
Part Number: 2CPX041816R9999
Quick Summary
The 2CPX041816R9999 cable connection module from ABB enables safe, organized wiring in CombiLine distribution panels. Engineers struggle with cluttered cable routing and limited enclosure space, which slows assembly and increases fault risk. It complies with DIN EN 61439-3 and DIN EN 61439-2, with CE conformity and RoHS compliance. Designed for interior fittings with fixed mounting and 12 DIN unit capacity, it delivers predictable panel depth and scalable modularity, supporting efficient panel builds and easier maintenance in control cabinet assemblies.
Product Information
Extended Description
2CPX041816R9999 ABB: Interior fitting module, CombiLine, Modular distribution panel not assembled, for Cable connection module, Grid unit 1 GU = 150 mm, panel width 1 = 250 mm, 12 Space units, Fixed mounting, covers out of Plastic, 90 degree press and turn closure, RAL 7035, Design of the cover: with cut-out, usuable as of the cabinet depth of 225 mm
Rated Operational Voltage
Maximum 400 V
Enclosure Type
Interior fitting module
Enclosure Type of Height
0000
Mounting Type
Fixed mounting
DIN Place Units
12
Meter Boards
0
Module Function
Cable connection module
RAL Number
RAL 7035 - Light Grey
Color
Light grey
RoHS Information
EU Declaration of Conformity Distribution Panel System CombiLine N
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date
20240903
REACH Declaration
Declaration regarding the REACH – Regulation ABB STRIEBEL & JOHN
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20240902
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
Product Not in WEEE Scope
Product Net Width
250 mm
Product Net Height
150 mm
Product Net Depth / Length
225 mm
Section Width
1
Product Net Weight
1.42 kg
Built-In Depth (t2)
225 mm
Package Level 1 Units
pack 1 piece
Package Level 1 Gross Weight
1.42 kg
Declaration of Conformity - CE
EU Declaration of Conformity Distribution Panel System CombiLine N
Instructions and Manuals
Mounting instruction MBV180-282
Data Sheet, Technical Information
Catalogue for panel builders 2024/2025 Intro | Catalogue for wholesalers 2025 Intro
ETIM 8
EC001893 - Distributor assembly for device surface mounting
ETIM 9
EC001893 - Distributor assembly for device surface mounting
eClass
V11.0 : 27400608
Object Classification Code
U
Standards
DIN EN 61439-3 | DIN EN 61439-2
