ABB 2CPX042022R9999 Copper Busbar Set - DIN 43673-1
Part Number: 2CPX042022R9999
Quick Summary
ABB 2CPX042022R9999 is a copper busbar set designed for CombiLine modular distribution panels in industrial control cabinets. The goal is to provide a reliable, scalable means to interconnect cabinet sections as panels grow or reconfigure. Engineers often struggle with high contact resistance, space constraints, and complex wiring during panel expansions; this busbar solution minimizes those risks with a precise, copper busbar connection set that fits cabinet-to-cabinet connections. It carries CE conformity, RoHS compliance, and a REACH declaration, supporting regulatory readiness across Europe. Used with ABB CombiLine systems, it simplifies installation, reduces labor time, and lowers maintenance costs, delivering consistent electrical performance and long-term reliability for data centers, manufacturing lines, and control centers.
Product Information
Extended Description
2CPX042022R9999 ABB: Copper busbar connection set, CombiLine, Modular distribution panel not assembled, rated current maximum 320 A
Rated Current (In)
320 A
Number of Poles
1P
Connection Type
Cabinet / Cabinet
Enclosure Type
Copper busbar connection set
DIN Place Units
0
Meter Boards
0
RoHS Information
EU Declaration of Conformity Distribution Panel System CombiLine N
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date
20240903
REACH Declaration
Declaration regarding the REACH – Regulation ABB STRIEBEL & JOHN
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20240902
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Product Net Width
94 mm
Product Net Height
5 mm
Product Net Depth / Length
100 mm
Product Net Weight
0.101 kg
Package Level 1 Units
pack 1 piece
Package Level 1 Gross Weight
0.108 kg
Declaration of Conformity - CE
EU Declaration of Conformity Distribution Panel System CombiLine N
Instructions and Manuals
Mounting instruction ZX1182-..86 / ZX1192-..96
Data Sheet, Technical Information
Catalogue for panel builders 2024/2025 Intro | Catalogue for wholesalers 2025 Intro
ETIM 8
EC000713 - Busbar coupler
ETIM 9
EC000713 - Busbar coupler
eClass
V11.0 : 27400606
Object Classification Code
U
Standards
DIN 43673-1
Feature → Business Impact → Application: Rated current up to 320 A and a single-pole configuration provide a robust, low-resistance path for modular panels. Business Impact: This reduces the need for parallel conductors, lowers install time, and minimizes voltage drop in crowded switchgear. Application: Ideal for CombiLine modular distribution panels in automation cabinets. Feature: Copper busbar enclosure delivers inherently low contact resistance and durable mating with cabinet busbars. Business Impact: Improves thermal performance, stabilizes current transfer, and reduces maintenance frequency due to superior contact quality. Application: Suitable for cabinet-to-cabinet interconnections in power distribution networks across manufacturing facilities. Feature: RoHS and REACH compliance with CE Declaration ensures regulatory readiness. Business Impact: Streamlines procurement, minimizes compliance risk, and supports auditing requirements. Application: Required for European sites handling electrical distribution equipment. Feature: Compact dimensions (94 mm width, 5 mm height, 100 mm depth) and weight of 0.101 kg keep a small footprint. Business Impact: Enables installation in tight panels and reduces overall cabinet weight, improving airflow and serviceability. Application: Aligns with mounting instructions ZX1182-..86 / ZX1192-..96 and ETIM/ eClass classifications. Feature: Unit packaging (pack 1 piece) and precise tolerances stabilize inventories and installation planning. Business Impact: Predictable lead times and stocking simplify project scheduling for panel builders. Application: Suited for automated assembly lines and site refurbishments using CombiLine systems.
