ABB 2CPX044418R9999 Busbar holder - RoHS Compliant
Part Number: 2CPX044418R9999
Quick Summary
ABB 2CPX044418R9999 busbar holder enables compact modular distribution for switchgear panels. Engineers often struggle with space constraints and precise busbar alignment that slow commissioning and increase risk of misfeed. This part carries CE conformity with EU RoHS compliance and REACH declarations for regulated environments. Designed for CombiLine modular panels and busbar systems, it reduces installation time and improves reliability by providing a stable mounting point. Its robust plastic construction, 800 A rating, and 4P configuration deliver scalable performance across industrial automation and power management applications.
Product Information
Extended Description
2CPX044418R9999 ABB: Busbar holder, CombiLine, Modular distribution panel not assembled, Busbar center distance: 185 mm, rated current maximum 800 A
Rated Current (In)
800 A
Model Number
Fastening parts/-set
Number of Poles
4P
Enclosure Type
Busbar holder
Material
Plastic
Color
Grey (mouse grey)
RoHS Information
EU Declaration of Conformity Distribution Panel System CombiLine N
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date
20240903
REACH Declaration
Declaration regarding the REACH – Regulation ABB STRIEBEL & JOHN
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20240902
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
Product Not in WEEE Scope
Product Net Width
235 mm
Product Net Height
50 mm
Product Net Depth / Length
10 mm
Product Net Weight
0.775 kg
Package Level 1 Units
pack 1 piece
Package Level 1 Gross Weight
0.806 kg
Declaration of Conformity - CE
EU Declaration of Conformity Distribution Panel System CombiLine N
Instructions and Manuals
Mounting instruction ZX2610-33
ETIM 8
EC001896 - Distributor assembly busbars
ETIM 9
EC001896 - Distributor assembly busbars
eClass
V11.0 : 27400610
Object Classification Code
U
High current capacity: Rated to 800 A with 4P configuration, this busbar holder supports substantial load in a single component. Business impact: reduces the number of parallel busbar segments, cutting hardware counts and simplifying protection schemes. Application: ideal for ABB CombiLine modular distribution panels in heavy automation and manufacturing facilities. Modular integration and non-assembled design: The component ships as a modular busbar holder that integrates with the CombiLine system without a full panel assembly. Business impact: speeds commissioning, lowers on-site labor, and minimizes field rework. Application: suitable for retrofits and new builds in switchgear cabinets. Compact footprint: With 235 mm width, 50 mm height, and 10 mm depth, it saves cabinet space and improves cable management. Business impact: denser layouts mean fewer enclosures, reduced cooling load, and lower installation costs. Application: optimized for compact distribution panels in bottlenecked automation lines. Material and compliance: Constructed from lightweight plastic and finished in grey, it offers durability without excessive weight. RoHS and CE declarations guarantee regulatory compliance, REACH information is provided, and WEEE category indicates disposal expectations. Business impact: reduces risk of non-compliance penalties and simplifies supplier qualification. Application: essential in regulated industrial environments and global deployments. Compatibility and installation: Designed for CombiLine and busbar center distance of 185 mm; mounting instruction ZX2610-33 guides secure installation. Business impact: ensures reliable electrical contact and mechanical stability, minimizing return visits. Application: suitable for new builds, refurbishments, and OEM panel assemblies in power management and distribution.
Get a Quick Quote for a ABB 2CPX044418R9999
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 2CPX044418R9999?
Enquire Now
FAQs
Install by following ZX2610-33 mounting instructions. Align the busbar holder to the 185 mm center distance and secure with the appropriate fastening parts for a 4P configuration. Ensure the panel area is prepared for space and that the unit sits flush to avoid misalignment. Weighs approx 0.775 kg.
The component is rated for 800 A and supports 4 poles (4P). This combination is suitable for main feeders in heavy automation and power distribution, delivering reliable performance under peak loads and maintaining safe thermal margins in ABB CombiLine systems.
Yes. Its compact footprint and modular design optimize space in dense control panels. It integrates with CombiLine, supports efficient cable routing, and reduces cabinet footprint while preserving ease of maintenance and future expansion in automation or process control environments.
CE declaration of conformity and EU RoHS compliance with the 20115/863 amendment are provided, along with REACH information and WEEE status indicating disposal considerations. ETIM and eClass classifications support cataloging in modern procurement systems, aiding regulatory compliance and supplier qualification.
By reducing mounting time and minimizing misalignment risk, installation overhead drops and commissioning can be faster. The stable plastic housing and robust fastening improve reliability, lowering maintenance visits and spare parts. Over the lifecycle, this translates to lower total cost of ownership in power distribution applications.
