ABB 2CPX064819R9999 Terminals - CE Declaration
Part Number: 2CPX064819R9999
Quick Summary
ABB 2CPX064819R9999 terminals enable safe distribution in control panels for industrial automation. Engineers often struggle with wiring density, space constraints, and the risk of misconnection during panel builds. They align with CE conformity, RoHS compliance, and REACH declarations, supporting compliant manufacturing and easy supplier audits. Direct mounting and 27 clamp positions offer compact layouts and faster commissioning, while the 2P design enhances reliability in busy automation environments. In practice, customers report reduced wiring errors and improved serviceability. This combination translates to lower total cost of ownership and quicker project delivery.
Product Information
Extended Description
2CPX064819R9999 ABB: N/PE screw terminal set for distribution panels, 27 terminal points per pole
Rated Operational Voltage
Maximum 230 V
Operational Voltage
230 V
Rated Current (In)
63 A
Number of Poles
2P
Number of Clamp Positions
27
Enclosure Type
Terminals
Mounting Type
Direct mounting
Terminal Connection Type
Side
Insulation Material
Thermoplastic
Rated Cross-Section
1 - Solid-Core 1,5...16 mm² | 2 - Fine-Strand with Cable End Sleeve 0,75...10 mm² | 3 - Fine-Strand without Cable End Sleeve 0 mm² | 4 - Multi-Wired 10 mm²
RoHS Information
EU Declaration of Conformity ComfortLine Meter board system A
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date
20240916
REACH Declaration
Declaration regarding the REACH – Regulation ABB STRIEBEL & JOHN
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20240902
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Product Net Width
206 mm
Product Net Height
47 mm
Product Net Depth / Length
46 mm
Product Net Weight
0.31 kg
Package Level 1 Units
pack 1 piece
Package Level 1 Gross Weight
0.322 kg
Declaration of Conformity - CE
EU Declaration of Conformity ComfortLine Meter board system A
Instructions and Manuals
Mounting instruction zu ZK 219
ETIM 8
EC001284 - Single- and multi-pole terminal strip
ETIM 9
EC001284 - Single- and multi-pole terminal strip
eClass
V11.0 : 27141106
Object Classification Code
U
N/PE screw terminal set for distribution panels with 27 clamp positions per pole increases connection density, reducing panel width and simplifying cable routing. Direct mounting and side terminal connections enable quick, vibration-resistant installation, cutting assembly time and improving reliability in harsh environments. Thermoplastic insulation with versatile cross-section options supports 1 Solid-Core 1.5–16 mm², 2 Fine-Strand with Cable End Sleeve 0.75–10 mm², 3 Fine-Strand without Sleeve 0 mm², and 4 Multi-Wired 10 mm², reducing stocking needs and enhancing adaptability for mixed cabling in control cabinets. Rated 230 V and 63 A ensures compatibility with common automation loads, providing predictable performance and regulatory compliance. RoHS, REACH, WEEE compliance, ETIM EC001284 classification, and CE declaration simplify audits, traceability, and supplier qualification, while maintaining robust electrical safety and long service life in factory automation.
Get a Quick Quote for a ABB 2CPX064819R9999
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 2CPX064819R9999?
Enquire Now
FAQs
To install the ABB 2CPX064819R9999 terminal, mount directly on the distribution panel, orient the side connections for easy access, and tighten each terminal with the appropriate tool. The design provides 27 clamp positions per pole and a 2P configuration, which simplifies wiring planning and reduces mounting time during panel fabrication.
The terminal strip is rated for 230 V and 63 A, with two poles and 27 clamp positions per pole. The side terminal connection supports reliable wiring under vibration, while the direct-mount design minimizes enclosure depth and helps maintain clean wiring routes in compact panels. This setup also supports standard automation loads with improved serviceability.
Yes. The device supports solid-core cables 1.5–16 mm² and fine-strand wires 0.75–10 mm² with cable end sleeves, plus fine-strand without sleeves up to 0 mm² and multi-wired up to 10 mm². This flexibility makes it suitable for mixed cabling in control cabinets and provides a single solution for diverse panel requirements.
It carries a CE Declaration of Conformity and adheres to RoHS and REACH regulations, with WEEE categorization for small equipment. In addition, it aligns with ETIM EC001284 classification and eClass V11.0, helping engineers meet regulatory obligations and simplify vendor qualification and auditing processes.
Adopting this terminal delivers tangible benefits: faster, error-free wiring through direct mounting and standardized clamp geometry; reduced stock complexity by supporting multiple cross-sections; and ensured regulatory compliance, which lowers audit risk and supports longer service life in harsh industrial environments.
