ABB 2CPX077995R9999 ComfortLine Meter Board - IP44
Part Number: 2CPX077995R9999
Quick Summary
ABB 2CPX077995R9999 ComfortLine Meter Board is a surface-mounted cabinet solution for 5-row distribution in industrial facilities. Engineers often wrestle with limited floor space and complex wiring when assembling metering and distribution panels; this unit is designed to maximize footprint efficiency while simplifying installation. The cabinet carries CE conformity, RoHS compliance, and IP44 protection, with REACH and CMRT documentation to support supplier declarations. It is built on the ComfortLine cabinet concept, featuring 800 x 550 x 215 mm dimensions, 250 A rated current, and 120 DIN place units across five rows. Compatible with DIN rails and not pre-wired, it offers scalable, compliant power distribution for commercial and light industrial applications.
Product Information
Extended Description
2CPX077995R9999 ABB: Meter board, series ComfortLine, assmebled cabinet, with Metering cross, degree of protection IP44, rated current 250 A, dimensions in mm (H x W x D): 800 x 550 x 215, not pre-wired, Number of reserve spaces 1, Number of distributor rows 5, Grid unit 5 GU, Overall height 1, panel width 2, Space units 120, covers out of Plastic, RAL 7035
Rated Current (In)
250 A
Model Number
1-story
Number of Meter Cabinets
0
Number of Meter Panels
1
Number of Panel Widths
1
Number of Rows
5
Number of TSG Panels
0
Lower Connection Space
with DIN Rails (Top Hat Rails)
Enclosure Type
Meter board
Enclosure Type of Height
1
Mounting Type
Surface mounted/partially recessed mounted
Material
sheet steel
DIN Place Units
120
RoHS Information
EU Declaration of Conformity ComfortLine Cabinet System Type A/B
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date
20240903
REACH Declaration
Declaration regarding the REACH – Regulation ABB STRIEBEL & JOHN
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20240902
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Degree of Protection
IP44
Product Net Width
550 mm
Product Net Height
800 mm
Product Net Depth / Length
215 mm
Section Width
2
Product Net Weight
23.528 kg
Built-In Depth (t2)
215 mm
Package Level 1 Units
pack 1 piece
Package Level 1 Gross Weight
24.469 kg
Declaration of Conformity - CE
EU Declaration of Conformity ComfortLine Cabinet System Type A/B
Instructions and Manuals
Mounting instruction BX2/KS...EX2-cabinet | Mounting instruction A-Schrank | Mounting instruction ComfortLine Cabinet
ETIM 8
EC000262 - Meter cabinet equipped
ETIM 9
EC000262 - Meter cabinet equipped
eClass
V11.0 : 27142418
Object Classification Code
U
High-rated protection IP44 and robust sheet steel enclosure limits dust ingress and moisture exposure, reducing maintenance cycles and increasing panel longevity. This translates to lower downtime and safer operation in factory floors or outdoor-adjacent installations. The meter board provides 5 rows with 120 DIN place units, enabling structured metering and distribution within a single panel footprint; this supports faster commissioning and easier future capacity expansion where space is at a premium. Not pre-wired by default, it minimizes on-site wiring time and allows tailored field connections that match specific project schematics, boosting installation efficiency and reducing labor costs. Compliance-focused design includes RoHS and REACH declarations, CMRT, and a CE declaration, ensuring regulatory alignment for regulated markets and supplier transparency. WEEE classification and 4 Large Equipment category guidance support proper end-of-life management and asset tracking for compliance-driven organizations. The mounting flexibility of surface-mounted or partially recessed installation, plus compatibility with DIN rails, simplifies retrofits and new builds alike, enabling seamless integration with existing ABB ComfortLine systems and modular expansion in growing facilities.
Get a Quick Quote for a ABB 2CPX077995R9999
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 2CPX077995R9999?
Enquire Now
FAQs
Begin by preparing a clean panel cutout that accommodates 800x550x215 mm and ensure the lower connection space is available for DIN rail mounting. Mount the sheet steel enclosure on a sturdy surface, attach the DIN rails, and connect field wiring to the lower space. Since the unit is not pre-wired, follow the supplied mounting instructions BX2/KS for ComfortLine cabinets and use standard DIN rail accessories to integrate with existing distribution setups.
Key specs include a rated current (In) of 250 A, IP44 protection, and dimensions of 800 mm (H) x 550 mm (W) x 215 mm (D). It supports 120 DIN place units across 5 rows and is designed for surface mounted or partially recessed installation. The enclosure is made from sheet steel and designed to fit within the ComfortLine cabinet family, ensuring reliable metering and distribution under typical industrial conditions.
Yes. The meter board is specified for 5 rows with 120 DIN place units, a 250 A rating, and a 800x550x215 mm footprint, making it ideal for compact, multi-meter distribution in manufacturing environments. Its IP44 protection and compatibility with DIN rails support safe, scalable deployment in plant panels and service centers.
The unit includes CE conformity, RoHS compliance with EU Directive 2011/65/EU and amendment 2015/863, REACH declarations, CMRT, and a WEEE classification (4 Large Equipment). These documents help validate regulatory compliance, supply chain transparency, and responsible end-of-life management for utility and industrial projects.
Not pre-wired by design, it reduces pre-install customization time while offering flexible field wiring and straightforward installation with existing ComfortLine components. Its modular 5-row layout and 120 DIN place units enable scalable capacity with minimal panel remodeling, lowering total project cost and shortening commissioning timelines in both new builds and retrofits.
