2CSY289701R9003
Part Number: 2CSY289701R9003
Product Information
Extended Description
2CSY289701R9003 ABB: Device equipped with:2 rocker switches; 2 binary input channels that can be used to interface to KNX system conventional push-buttons/rocker switches, or auxiliary/technical contacts.
LEDs for the functional signaling of the load to which the rocker switch is connected.
Flush-mounted installation.
Mounting Type
Flush Mounted
Degree of Protection
IP20
Data Sheet, Technical Information
Technical Data (.PDF) [EN] 2CSYK9003C
Suitable For
2-wire
Number of Inputs
2
Product Range
KNX
Number of Batteries
0
Input Voltage (Uin)
20...20 V
Input Voltage Type
DC
Power Supply Type
Bus System
Design Range
Mylos
Width in Number of Modular Spacings
0
Product Net Width
43 mm
Product Net Height
44 mm
Product Net Depth / Length
44 mm
Product Net Weight
0.07 kg
Built-In Depth (t2)
43 mm
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B
Business To Consumer
Declaration of Conformity - CE
CE & RoHS Declaration of Conformity (.PDF) [XX] 2CSYK100XX
ETIM 9
EC002971 - System device clinic-installation
