ABB 3ABD00039408-D Motor Drive - IP20 Protection
Part Number: 3ABD00039408-D
Quick Summary
ABB 3ABD00039408-D motor drive optimizes low-voltage AC motor control for industrial automation applications. Engineers often contend with space constraints, harmonic distortion, and complex integration when upgrading legacy drives. This module is CE-certified with IP20 protection and offers optional functional safety features to help address SIL-rated environments. Its compact design, built-in harmonic filtering, and flexible mounting translate into faster deployments, lower wiring, and reliable control for conveyors, pumps, cranes, and more. By consolidating drive, filtering, and safety options in a single platform, it reduces total cost of ownership. This helps OEMs and end users meet demanding uptime, regulatory, and safety standards.
Product Information
Extended Description
3ABD00039408-D ABB: The ACS880-04 drives are customized to meet the particular needs of specific industries, such as oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive. They can control a wide range of applications, including cranes, extruders, winches, winders, conveyors, mixers, compressors, centrifuges, test benches, elevators, extruders, pumps, and fans. The ACS880-04 modules have all the essential features built-in, including a choke for harmonic filtering as standard, and options such as a brake chopper, EMC filter and communication protocol adapter, functional safety and I/O extension modules. The all built-in design combined with IP20 protection significantly simplifies engineering. The drive=E2=80=99s compact size, flexible cabling directions and versatile mounting possibilities from narrow bookshelf to flat mounting and horizontal mounting make it an ideal fit for almost any enclosure. The control unit with I/O and communication connections can be mounted outside the power module or integrated into it.
Paragraph 1: Feature: Built-in harmonic filtering choke is included as standard. Impact: reduces harmonic currents and EMI, easing compliance with power quality standards and decreasing the need for external filters in demanding installations. Application: ideal for high‑demand lines like conveyors, pumps, mixers, and extruders in mining, metals, chemicals, and pulp and paper plants. Paragraph 2: Feature: All-in-one drive design with IP20 protection. Impact: simplifies engineering, shortens panel fabrication, and lowers enclosure footprint by consolidating drive electronics into a compact unit. Application: fits compact control cabinets and supports quick field installation across automotive, food & beverage, and material-handling facilities; compatibility with standard mounting patterns reduces integration time. Paragraph 3: Feature: Rich option set including brake chopper, EMC filter, protocol adapter, functional safety, and I/O extension. Impact: lets you tailor the drive to exact plant requirements without adding multiple devices, reducing integration risk and total cost of ownership. Application: cranes, winders, elevators, automated warehouses, and other heavy-duty systems. Paragraph 4: Feature: Flexible control unit mounting. Impact: the module's control unit can be mounted outside the power module or integrated, enabling versatile cabling directions and mounting in narrow or front-facing enclosures. Application: retrofit projects, OEM designs, and installations with limited vertical space. Paragraph 5: Feature: High-power performance and broad compatibility. Impact: Pn 560 kW and 820 A capacity support demanding industrial loads while maintaining precise speed and torque control, improving uptime and process stability. Application: heavy industry processes such as mining, metals processing, cement, and large pumps or fans.
Get a Quick Quote for a ABB 3ABD00039408-D
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3ABD00039408-D?
Enquire Now
FAQs
The 3ABD00039408-D module is designed to integrate into LV AC control architectures and aligns with standard mounting practices used for ACS880-04 family. It supports compact enclosure mounting, flexible cabling directions, and a control unit that can be mounted outside the power module or integrated. Ensure compatible communication interfaces and verify the plant’s power quality requirements to determine if additional EMC filtering or chokes are necessary for optimal performance.
Key performance specs include a Pn of 560 kW and current capability of 820 A. The drive features built-in harmonic filtering, IP20 protection, and an all-in-one design to simplify installation. These attributes support precise speed control, high torque at low speeds, reduced motor stress, and improved process stability in cranes, conveyors, pumps, and mixers.
The module is CE-certified and offers optional functional safety features that support compliance in SIL-rated environments. While the base unit provides robust safety options, confirm your specific SIL level requirements and select the appropriate safety modules (e.g., safety I/O extensions) to achieve the desired certification level for your application.
The all-in-one design reduces wiring complexity, panel space, and the number of separate components, which lowers installation time and maintenance overhead. Built-in harmonic filtering reduces external accessories and improves power quality, contributing to longer motor life and fewer spare parts. These factors translate into faster time-to-operate and lower total cost of ownership over the asset lifecycle.
Common challenges include enclosure space constraints and cabling routing in tight panels. Mitigation steps include leveraging the IP20-rated, compact enclosure, choosing the external or integrated control unit mounting option based on space, and planning cabling routes with the built-in connector orientations in mind. Pre-checks for harmonic compliance and safety module compatibility will further ease deployment.
