ABB 3ABD00039544-D LV AC Drive Module - Harmonic Filter
Part Number: 3ABD00039544-D
Quick Summary
ABB 3ABD00039544-D LV AC industrial drive module controls motor speed and torque for heavy industry applications. Engineers often struggle with integrating drives into compact enclosures while battling harmonic distortion and wiring complexity. This module combines built-in harmonic filtering, IP20-ready protection, and flexible mounting options to streamline panel design. CE-compliant configurations and optional functional safety modules support regulatory and safety requirements across process industries. By consolidating drive, protection, and connectivity in a single compact unit, it reduces engineering time, minimizes enclosure size, and lowers total cost of ownership for end users in mining, metals, and food and beverage sectors.
Product Information
Extended Description
3ABD00039544-D ABB: The ACS880-04 drives are customized to meet the particular needs of specific industries, such as oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive. They can control a wide range of applications, including cranes, extruders, winches, winders, conveyors, mixers, compressors, centrifuges, test benches, elevators, extruders, pumps, and fans. The ACS880-04 modules have all the essential features built-in, including a choke for harmonic filtering as standard, and options such as a brake chopper, EMC filter and communication protocol adapter, functional safety and I/O extension modules. The all built-in design combined with IP20 protection significantly simplifies engineering. The drive=E2=80=99s compact size, flexible cabling directions and versatile mounting possibilities from narrow bookshelf to flat mounting and horizontal mounting make it an ideal fit for almost any enclosure. The control unit with I/O and communication connections can be mounted outside the power module or integrated into it.
Feature: Built-in harmonic filtering and choke for harmonic suppression → Business Impact: Reduces external filter needs, lowers panel cost, improves power quality → Application: Oil & gas, mining, and metals processing lines. Feature: All-in-one design with IP20 protection → Business Impact: Simplifies enclosure design, shortens installation time, and enhances reliability → Application: Cabinet-based control in manufacturing environments with limited space. Feature: Flexible mounting and compact footprint → Business Impact: Easier integration into narrow or customized enclosures, faster commissioning → Application: Conveyors, cranes, and winches in material handling facilities. Feature: Optional brake chopper, EMC filter, and protocol adapters → Business Impact: Seamless integration with existing control networks, improved electromagnetic compatibility, and safer braking options → Application: Packaging lines and paper/pulp processing. Feature: I/O extension and safety options → Business Impact: Scales with plant automation needs while meeting safety standards, reducing retrofit costs → Application: Food & beverage and chemical processing facilities.
Get a Quick Quote for a ABB 3ABD00039544-D
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3ABD00039544-D?
Enquire Now
FAQs
The 3ABD00039544-D is designed for flexible mounting in cabinets with IP20 protection. When installing, consider cable routing from the control unit to field devices, ensure adequate ventilation, and plan for external connections if mounting outside the power module. Optional I/O extension modules and protocol adapters simplify integration with existing automation systems.
Key specifications include a power rating of Pn 710 kW and a current rating of 721 A. The drive features a built-in harmonic filtering choke, IP20 protection, and compatibility with brake choppers, EMC filters, and communication adapters. It supports a wide range of load types, from conveyors to pumps and winches.
Yes. The ACS880-04 family offers options such as protocol adapters and I/O extension modules to align with established control architectures. This enables seamless communication with common industrial networks, reducing engineering time and ensuring reliable data exchange with PLCs, SCADA, and MES systems.
Industries with demanding motor control needs, such as oil & gas, mining, metals, chemicals, cement, and packaging, benefit most. Typical applications include cranes, conveyors, pumps, fans, mixers, and compressors. The built-in harmonic filtering and compact design help protect power quality and simplify installation in harsh environments.
Optional functional safety modules can be added to meet regulatory requirements, along with brake chopper and EMC filter options to support safe operation and electromagnetic compatibility. Regular maintenance focuses on insulation integrity, connector integrity, and periodic parameter validation to sustain performance in demanding production lines.
