ABB ACH531-01-09A5-4+P973 Wall-Mounted Drive - IP20
Part Number: 3ABD00058693-D
Quick Summary
ACH531-01-09A5-4+P973 wall-mounted drive is designed to control fans, pumps, and compressors in HVAC systems. By integrating essential startup, commissioning, and monitoring functions, it minimizes field wiring and reduces installation time. This device carries CE conformity and an IP20 enclosure, enabling safe, compliant installation in wall-mount spaces and demanding environments. Optional Bluetooth connectivity enables remote commissioning and monitoring, helping service teams act quickly without on-site visits. With built-in energy-management features, it supports reliable operation across normal and mission-critical HVAC applications while delivering a lower total cost of ownership.
Product Information
Extended Description
3ABD00058693-D ABB: The ACH531 drive offering has all key features built-in to control fans, pumps and compressors, and more complex equipment like air-handling units and chillers, ensuring a smooth, energy-efficient operation of your HVAC systems in normal and mission-critical situations. The built-in features significantly reduce installation time and the standard basic control panel can make startup, commissioning, and operation easy. The optional Bluetooth=C2=AE capability enables the commissioning and monitoring of the drive from a distance. The ACH531-01 comes in an IP20 enclosure and can be installed on the wall as standard.
Built-in control functions for fans, pumps, and compressors provide centralized supervision; this reduces external controllers, speeds startup, and lowers wiring complexity, which translates to shorter project timelines and lower installation costs. In HVAC applications such as air-handling units and chillers, the integrated control improves response times and enables tighter process control, boosting overall system reliability. IP20 enclosure and wall-mount design simplify installation in mechanical rooms and on-wall spaces, reducing cabinet footprint and enabling flexible siting. Optional Bluetooth connectivity enables remote commissioning and monitoring, cutting on-site visits and accelerating service delivery for retrofit projects and new builds. The 4 kW, 9.4 A rating supports mid-size HVAC loads with ample torque, ensuring consistent operation across fans, pumps, and compressors. Energy-efficient operation and a built-in basic control panel help facilities meet performance targets while minimizing operating costs over the equipment lifecycle.
Get a Quick Quote for a ABB 3ABD00058693-D
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3ABD00058693-D?
Enquire Now
FAQs
Begin by selecting a suitable wall-mount location that provides adequate clearance for cooling and wiring. Mount the unit on a clean, vibration-free surface, connect the supply and motor leads per the ACH531 wiring diagram, and enable the CE-compliant setup. Use the built-in basic panel to perform the initial startup and parameterization, then verify control of fans, pumps, and compressors through the built-in monitoring interface. Ensure Bluetooth is configured if remote monitoring is planned.
Key specifications include a 4 kW power rating and 9.4 A current rating, IP20 enclosure, and wall-mounted form factor. These ratings indicate suitability for mid-size HVAC loads such as fans, pumps, and compressors. Compatibility with air-handling units and chillers should be confirmed against Load, torque, and duty cycle requirements. Remember to plan for ambient conditions and motor protection coordination within the system.
Yes. The ACH531-01-09A5-4+P973 is designed to control HVAC equipment including air-handling units and chillers, delivering smooth speed control, improved process stability, and energy efficiency. Its integrated features reduce commissioning time and simplify protection strategies for critical equipment. When integrating with AHUs or chillers, verify wiring compatibility, sensor inputs, and soft-start settings to optimize performance.
The drive is CE-conformant and features an IP20 enclosure for safe, indoor installation. The CE marking ensures compliance with European safety and EMC standards, while the IP20 rating provides protection against dust ingress and solid objects at low levels, suitable for controlled indoor environments. Optional Bluetooth enables remote monitoring and commissioning, expanding installation flexibility.
By reducing wiring complexity, shortening startup times, and enabling remote monitoring, the ACH531-01-09A5-4+P973 lowers installation and on-site service costs, contributing to quicker project payback. Maintenance focuses on periodic parameter validation, firmware updates if available, and routine checks of motor current and cooling to prevent faults. The built-in features also help minimize unscheduled downtime in mission-critical HVAC operations.
