ABB 3ABD00059700-D Drive Module - IP20 Built-in Harmonic Filter
Part Number: 3ABD00059700-D
Quick Summary
ABB 3ABD00059700-D Drive Module provides precise position control for cranes, conveyors, and pumps. Engineers often struggle with complex wiring, harmonics, and space constraints that delay deployment and increase risk. The module features IP20 protection and functional safety options that enable SIL-ready configurations, aligning with common industrial safety practices. Its compact design, flexible mounting, and built-in harmonic filter simplify engineering workflows, while its robust control unit supports external mounting or integration inside the power module. This combination delivers faster commissioning, reduced BOM, and improved uptime in demanding automation environments.
Product Information
Extended Description
3ABD00059700-D ABB: The ACS880-04 drives are customized to meet the particular needs of specific industries, such as oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive. They can control a wide range of applications, including cranes, extruders, winches, winders, conveyors, mixers, compressors, centrifuges, test benches, elevators, extruders, pumps, and fans. The ACS880-04 modules have all the essential features built-in, including a choke for harmonic filtering as standard, and options such as a brake chopper, EMC filter and communication protocol adapter, functional safety and I/O extension modules. The all built-in design combined with IP20 protection significantly simplifies engineering. The drive=E2=80=99s compact size, flexible cabling directions and versatile mounting possibilities from narrow bookshelf to flat mounting and horizontal mounting make it an ideal fit for almost any enclosure. The control unit with I/O and communication connections can be mounted outside the power module or integrated into it.
Feature: Integrated choke for harmonic filtering is built into the drive module. Impact: reduces harmonic distortion at the source, lowers the need for external reactors, and helps meet utility and grid compliance while saving cabinet space. Application: improves performance for heavy conveyors, pumps, and winders in mining, cement, oil and gas facilities. Feature: Optional brake chopper and EMC filter enhance safety and EMI reduction. Impact: safer braking for heavy loads and reduced electromagnetic interference in signal-critical installations. Application: cranes, winches, conveyors in metals, pulp and paper, and marine environments. Feature: IP20-protected all-in-one design with compact footprint. Impact: simplifies engineering, reduces enclosure depth, and eases cabling in narrow shelves. Application: cabinet builders and panel builders; suitable for flat mounting and horizontal mounting. Feature: Control unit I/O and communications can be mounted outside or integrated. Impact: flexible installation reduces wiring complexity and enclosure size. Application: food & beverage lines, water treatment, and automotive assembly. Feature: Safety and I/O expansion options enable SIL-ready configurations. Impact: scalable safety compliance and future-proof automation. Application: critical process lines requiring reliable, compliant operation.
Get a Quick Quote for a ABB 3ABD00059700-D
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3ABD00059700-D?
Enquire Now
FAQs
Follow the standard ACS880-04 mounting guidelines: verify enclosure IP20 protection, mount the drive module securely, and route power, motor, and signal cables to minimize interference. Connect the I/O and communications per the adapter options, and decide whether the control unit will be mounted outside or integrated into the power module. Perform commissioning with baseline parameter checks to ensure accurate position control.
The module delivers up to 355 kW of power with a maximum current of 503 A. It provides precise position control, built-in harmonic filtering, IP20 protection, and options for brake chopper, EMC filter, and communications adapters to suit demanding industrial tasks.
Yes. With built-in harmonic filtering, robust IP20 protection, and flexible mounting, the 3ABD00059700-D supports conveyors, cranes, winches, and winders in mining, cement, oil & gas, and metals processing, delivering reliable control with reduced system complexity.
The module offers IP20 protection and functional safety options that enable SIL-ready configurations. This supports regulatory expectations for safety-critical automation while maintaining flexible I/O expansion for scalable fault-tolerant operation.
Benefits include reduced BOM from an integrated harmonic filter and braking options, faster commissioning, lower wiring complexity, and improved uptime due to reliable control. These factors collectively shorten payback periods in continuous-process environments.
