ABB 3ADT218522S0111 DC Converter Module - IP00
Part Number: 3ADT218522S0111
Quick Summary
ABB 3ADT218522S0111 DC Converter Module is designed to deliver high-current DC conversion for large industrial power systems. It supports 400 VAC inputs and handles up to 1190 A, making it ideal for DC bus configurations and heavy motor drive feeds. Engineers often face challenges with reliable current sharing, thermal management, and footprint when scaling power in compact spaces. This module addresses those concerns with robust enclosure dimensions, a 55 kg weight, and the proven reliability of the DCS880 platform. By aligning with IEC/EN protection standards and standard interfaces, it enables straightforward integration, improved uptime, and predictable maintenance planning for OEMs and system integrators. The result is safer operation, lower total cost of ownership, and faster project execution.
Product Information
Extended Description
3ADT218522S0111 ABB: DC Converter;
Type: DCS880-S01-1190-04;
2Q Converter;
Voltage: 400 VAC;
Current: 1190 A;
Weight: 55kg;
Country of Origin
Poland (PL)
Lead Time
35 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
DEAPREXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
Germany (DE)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND002EXPU
Warranty Return
Product under warranty must be returned
Customs Tariff Number
85044083
HS Code
850440-- Electrical transformers, static converters (for example, rectifiers) and inductors.- Static converters
Invoice Description
DC Converter;
Type: DCS880-S01-1190-04;
2Q Converter;
Voltage: 400 VAC;
Current: 1190 A;
Weight: 55kg;
Made To Order
No
Minimum Order Quantity
1 piece
Order Multiple
1 piece
Quote Only
No
Selling Unit of Measure
piece
Product Net Weight
55 kg
Product Net Depth / Length
368 mm
Product Net Height
768 mm
Product Net Width
270 mm
Package Level 1 Depth / Length
460 mm
Package Level 1 Height
470 mm
Package Level 1 Width
790 mm
Degree of Protection
acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP00
Operating Humidity (RHamb)
5...95%
Sound dB (A)
75 dB(A)
Frequency (f)
50 Hz | 60 Hz
Frame Size
H5
Analog Inputs
3
Analog Outputs
2
Product Name
DCS880 DC Converter Module
High-current 400 VAC input and 1190 A rating reduce the number of parallel devices and simplify wiring, cutting installation time and BOM cost. In the DCS880 DC Converter Module, this translates to a more compact power path and improved thermal performance for large motor drives and DC bus systems. IP00 protection, aligned with IEC 60529 and EN 60529 standards, supports safe cabinet mounting in controlled environments and minimizes field exposure. The module weighs 55 kg and measures 368 mm (L) x 270 mm (W) x 768 mm (H), offering a manageable footprint for space-constrained control rooms and machine builds. With 3 analog inputs and 2 analog outputs, it fits neatly into existing control architectures and enhances monitoring and control fidelity. Lead times vary by supplier region (35 days at DEAPR; 0 days as Configuration Only at SGIND002), and it is stocked at DEAPREXPU to support faster procurement. These factors collectively improve reliability, reduce downtime, and streamline project timelines for large-scale power systems.
Get a Quick Quote for a ABB 3ADT218522S0111
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3ADT218522S0111?
Enquire Now
FAQs
Yes. The 3ADT218522S0111 is designed to integrate with ABB's DCS880 DC Converter ecosystem, featuring standard interfaces and the H5 frame size. When mounting, consider the internal cabinet environment (IP00 protection implies enclosure-based use), required cable routing for 400 VAC input, and adequate clearance for heat dissipation. Ensure support structures match the 55 kg unit weight to prevent vibration and allow service access for analog I/O connections.
Core specs include 400 VAC input, 1190 A output, and a 50/60 Hz operating range. The unit weighs 55 kg and measures 368 mm long, 270 mm wide, and 768 mm tall (Frame H5). It provides 3 analog inputs and 2 analog outputs, with protection configured for IP00. These parameters support high-power DC distribution in industrial drives while ensuring predictable thermal behavior in standard control cabinets.
The 3ADT218522S0111 is well-suited for DC bus feeding and high-current power distribution in heavy machinery, steel processing, packaging lines, and large motor drives. Its 400 VAC/1190 A capability makes it ideal for centralized DC conversion in OEM assembly lines and system integrator projects where a single high-current converter can replace multiple lower-capacity devices, reducing wiring complexity and improving reliability.
Protection is defined to IEC 60529 and EN 60529 with an IP00 rating, indicating internal cabinet mounting practicality. The data references IEC 60947-1 as part of the applicable standards, supporting safe electrical performance in industrial environments. Always verify local electrical codes and enclosure requirements for cabinet design and ventilation when deploying in hazardous or restricted areas.
Warranty terms indicate standard return conditions for defective units, with a note that warranty returns must be managed through the vendor. Lead times vary by supplier region: 35 days from DEAPR and 0 days for Configuration Only stock from SGIND002. Stock availability at DEAPREXPU enables faster procurement. ROI is enhanced by reduced BOM count, simplified wiring, minimized parallel converters, and improved uptime due to reliable DCS880 integration.
