ABB 3ADT218606R0003 DC Rectifier - 525 V 225 A IP00
Part Number: 3ADT218606R0003
Quick Summary
ABB 3ADT218606R0003 DC Rectifier delivers robust DC power conversion for industrial drive and automation systems. Engineers often wrestle with panel wiring complexity, sourcing gaps, and inconsistent performance; this module streamlines integration with a pre-wired panel and clear 525 V / 225 A specifications. The design aligns with IEC 60529/IP00 protection and IEC 60947-1 guidelines, reinforcing safe operation in harsh factory environments. With ABB reliability and a compact footprint, it supports efficient DC supply in process control, robotics, and drive architectures, helping maintenance teams reduce downtime and spare part inventories.
Product Information
Extended Description
3ADT218606R0003 ABB: DC Rectifier ;
Typecode: DCS580-S01-0225-05X0;
Weight : 16 Kg
Voltage : 525 V;
Current : 225 A;
1 bridge / Rectifier;
incl. Panel;
Country of Origin
Poland (PL)
Lead Time
21 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
DEAPREXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
Poland (PL)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND002EXPU
Warranty Return
Product under warranty must be returned
Customs Tariff Number
85044083
HS Code
850440-- Electrical transformers, static converters (for example, rectifiers) and inductors.- Static converters
Invoice Description
DC Rectifier ;
Typecode: DCS580-S01-0225-05X0;
Weight : 16 Kg
Voltage : 525 V;
Current : 225 A;
1 bridge / Rectifier;
incl. Panel;
Made To Order
No
Minimum Order Quantity
1 piece
Order Multiple
1 piece
Quote Only
No
Selling Unit of Measure
piece
Product Net Weight
0 kg
Product Net Depth / Length
271 mm
Product Net Height
370 mm
Product Net Width
270 mm
Package Level 1 Depth / Length
390 mm
Package Level 1 Height
350 mm
Package Level 1 Width
390 mm
Degree of Protection
acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP00
Operating Humidity (RHamb)
5 ...95%
Sound dB (A)
55 dB(A)
Frequency (f)
50 Hz | 60 Hz
Frame Size
K2
Analog Inputs
2
Analog Outputs
2
Product Name
DCS580 DC Converter Module
High-current DC output with a 525 V rating and 225 A capacity enables a compact DC link for ABB drive systems and motor control panels. The integrated panel reduces field wiring and accelerates startup, delivering measurable improvements in deployment speed and reliability for automation projects. Pre-wired panel and 1 bridge rectifier simplify installation and minimize commissioning errors. In practice, technicians can connect quickly, improving first-pass acceptance and lowering on-site labor costs while maintaining precise electrical performance. Competitive lead times and regional stock (DEAPREXPU and SGIND002EXPU) ensure faster replenishment and fewer production stoppages, translating to lower inventory carrying costs and improved project cadence for OEMs and maintenance teams. Mechanical and electrical specs provide robust performance across 50/60 Hz and broad environmental conditions (IP00 protection, 5-95% humidity). Engineers can rely on predictable behavior in varying industrial climates, reducing risk of underspecification. Long-term value comes from compatibility with DCS580 DC Converter Module and 2 analog I/O channels, enabling flexible control strategies and easy future upgrades. The 16 kg unit balances portability with rigidity, helping installation in tight panel spaces.
