ABB 3AUA0000220436 HVAC Drive - Wall-Mount Ultra-low THDi
Part Number: 3AUA0000220436
Quick Summary
ABB HVAC drive is a wall-mounted controller delivering precise speed control for fans, pumps and compressors in HVAC systems. Engineers often struggle with harmonic distortion and complex wiring, but this drive reduces THDi and simplifies installation. Key certifications and features include a UL-listed design, IP21 enclosure, and optional IP55 or flange mounting to fit demanding spaces. Manufacturers benefit from reduced installation time and improved energy efficiency thanks to built-in features like active supply, line filter, and power factor correction, with Bluetooth monitoring available. This translates into easier commissioning, fewer field surprises, and reliable operation across mission-critical HVAC applications worldwide.
Product Information
Extended Description
3AUA0000220436 ABB: ACH580 HVAC drive offering has all key features built-in to control fans, pumps and compressors, and more complex equipment like air-handling units and chillers, ensuring smooth, energy-efficient operation of your HVAC systems in normal and mission-critical situations. This ultra-low variant provides ultimate harmonic performance, reaching even less than 3 % THDi, and exceeding the requirements set by low harmonic recommendations. The drive includes an active supply unit and integrated low harmonic line filter, meaning there is no need for external filters, multi-pulse arrangements or special transformers. Other features include output voltage boost and power factor correction. The built-in features significantly reduce installation time, and the intuitive HVAC specific control panel and help assistants make operation easy. The optional Bluetooth=C2=AE capability enables the commissioning and monitoring of the drive from a distance. The variant comes in IP21 enclosure as standard and can be installed on the wall. Also, IP55 and flange mounting units are available.
Ultra-low harmonic performance is a core feature, delivering THDi below 3% through an integrated low harmonic line filter and an active supply unit. This reduces distortion on the power system, improving compliance with utility guidelines and protecting sensitive equipment. In HVAC applications such as fans, pumps and compressors, the consequence is smoother startup, lower audible noise, and extended motor life. Installation and integration are streamlined as the drive’s built-in components eliminate the need for external filters or multi-pulse arrangements, shortening commissioning time and minimizing wiring complexity. The integrated features simplify retrofits and new installs in both new-builds and service projects, with IP21 standard enclosure suitable for indoor wall mounting. Optional IP55 and flange mounting units expand install flexibility. Power quality and efficiency are boosted by output voltage boost and power factor correction, improving overall drive efficiency and grid interaction for long cable runs. The 460 V, 14 A, 10 Hp rating aligns with common HVAC equipment, enabling direct compatibility with many fans and pumps, translating to measurable energy savings and faster ROI. Commissioning and remote monitoring are enhanced by optional Bluetooth capability for remote setup and diagnostics, while the HVAC-specific control panel and context-aware help assistants simplify parameter selection, fault analysis, and routine maintenance. This design supports consistent operation in mission-critical environments, with IP21 enclosure standard and additional options for harsher spaces. Reliability and readiness are further supported by IP55 and flange mounting options for tighter spaces, reducing spare parts needs and maintenance costs across HVAC plants such as air handling units and chillers.
Get a Quick Quote for a ABB 3AUA0000220436
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3AUA0000220436?
Enquire Now
FAQs
To install, verify the 460 V supply, connect to the drive’s input terminals, and mount the unit on a wall using the IP21 enclosure. The ACH580 supports 14 A and 10 Hp loads, offering integrated active supply and low harmonic filtering to minimize external components. Ensure proper cable sizing, motor compatibility, and follow the HVAC-specific commissioning procedure for parameter setup and protection settings. Bluetooth (optional) can simplify remote commissioning and diagnostics, reducing on-site time.
THDi below 3% means dramatically reduced harmonic distortion, improving power quality and reducing nuisance trips in electrical infrastructure. It’s achieved through the drive’s integrated low harmonic line filter and an active supply unit, which together suppress harmonics at the source without requiring external multi-pulse configurations or transformers. This is especially beneficial for large fans, pumps and compressors that run under varying loads in AHUs and chillers.
Yes. The ACH580 HVAC drive is designed for air handling units, chillers, fans, pumps and compressors, delivering precise control and steady operation in mission-critical HVAC applications. Its wall-mount form factor simplifies installation, while built-in filtering and harmonic suppression support compliant, reliable performance in variable-load scenarios typical of AHUs and central plant equipment.
The drive is UL-listed and ships with an IP21 enclosure as standard, suitable for indoor installation. Optional configurations include IP55 and flange mounting for more demanding environments or compact spaces. These certifications and ratings help ensure compliance with safety standards and installation flexibility in commercial buildings and industrial HVAC installations.
Expected ROI comes from energy savings due to improved power factor and reduced harmonic losses, plus quicker commissioning and fewer external components. Maintenance is typically reduced thanks to the integrated components and robust ABB platform; however, regular checks of filters (if external alternatives are not used), firmware updates, and monitoring via Bluetooth (if enabled) help maintain peak performance and minimize unexpected downtime.
