ABB ACH580-VDR-023A-4 HVAC Drive - UL Type 1 Enclosure
Part Number: 3AUA0000225657
Quick Summary
ACH580-VDR-023A-4 HVAC drive delivers precise motor control for commercial HVAC systems. When uptime matters, complex wiring and limited diagnostics can drive costly downtime. It uses a UL (NEMA) Type 1 enclosure with an integrated E-Clipse bypass, bypass starter, and electronic motor overload protection to simplify installation and maintenance. Designed for 1 to 75 hp at 230/460/575 V, it also offers an input disconnect switch or circuit breaker and fast-acting drive fuses. For broader regional deployments, ABB’s portfolio often includes CE-compliant and IP-rated variants, while this model focuses on indoor reliability and straightforward integration with building management systems. In short, you gain robust control, safer operation, and scalable performance for industrial HVAC applications.
Product Information
Extended Description
3AUA0000225657 ABB: The ACH580 with ABB E-Clipse bypass has an integrated UL (NEMA) Type 1 enclosure with a bypass motor starter and is available from 1 to 75 hp at 230/460/575 V. The ACH580 with ABB E-Clipse bypass provides an input disconnect switch or circuit breaker, both including fast acting drive fuses, with door mounted and interlocked switch (padlockable in the OFF position), a bypass starter, electronic motor overload protection, a door mounted control panel with graphical display for local control, provisions for external control connections, and serial communications capability
Feature → Business Impact → Application: The ACH580-VDR-023A-4 integrates an E-Clipse bypass with a bypass starter, enabling rapid maintenance without full system shutdown and reducing downtime in critical HVAC environments. This translates to lower service costs and improved system availability for air handlers and rooftop units. Feature → Business Impact → Application: A UL (NEMA) Type 1 enclosure with an input disconnect or circuit breaker plus fast-acting drive fuses enhances electrical safety, simplifies compliance, and accelerates panel installation, ideal for indoor HVAC installations in commercial buildings. Feature → Business Impact → Application: Electronic motor overload protection minimizes motor stress during startup and operation, extending motor life and reducing replacement cycles in high-load fans and pumps. Feature → Business Impact → Application: A door-mounted control panel with a graphical display speeds commissioning and on-site tuning, enabling quicker deployments and fewer commissioning errors in AHUs and variable air volume systems. Feature → Business Impact → Application: Serial communications capability and external control connections enable remote monitoring and seamless integration with building management systems, supporting energy management and performance analytics for large facilities.
Get a Quick Quote for a ABB 3AUA0000225657
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3AUA0000225657?
Enquire Now
FAQs
Yes. The drive supports 230, 460, and 575 V inputs with 1–75 hp output, making it suitable for a wide range of HVAC equipment. It provides an input disconnect switch or circuit breaker with fast-acting fuses and a door-mounted control panel for straightforward indoor installation in UL Type 1 (NEMA) enclosures.
Key protections include electronic motor overload protection, fast-acting drive fuses, and a bypass starter. These features guard motors during startup and operation, reduce nuisance trips, and simplify service by allowing the drive to bypass the motor for maintenance. This combination lowers unscheduled downtime and extends motor life in demanding HVAC loads.
Best suited for commercial and industrial HVAC tasks such as cooling tower fans, air handling units, rooftop units, and pumps in variable air volume systems. The E-Clipse bypass simplifies maintenance, while the door-mounted graphical display speeds commissioning. Serial communications and external control connections enable seamless integration with building management systems for energy optimization.
The unit features a UL (NEMA) Type 1 enclosure and UL-listed components suitable for indoor installation. This aligns with common industrial safety requirements for HVAC equipment. ABB also offers broader CE-compliant and IP-rated variants in other configurations to meet regional deployment needs.
The integrated bypass reduces downtime during service, and the advanced motor control minimizes energy waste and wear. Remote monitoring and diagnostics support predictive maintenance, lowering spare parts and labor costs. Overall, you gain faster restoration of service and energy savings, delivering a favorable return on investment for facilities with substantial HVAC load.
