ABB 3AXD50000428175 Drive Module - Ultra-Low THDi <3%
Part Number: 3AXD50000428175
Quick Summary
The ABB ACH580 ultra-low harmonic drive module provides LV AC control for HVAC systems. Engineers struggle with harmonic distortion and complex wiring when integrating fans, pumps, and chiller equipment. It ships with IP00 standard enclosures and an IP20 option for cabinet installs to meet demanding plant environments, while built-in low harmonic performance reduces THDi to under 3%. Designed for IEC power ratings up to 160 kW and 293 A, this drive supports energy-efficient operation and easier integration with HVAC controls. Optional Bluetooth enables remote commissioning and monitoring, and the HVAC-specific control panel speeds start-up and maintenance, delivering measurable business value.
Product Information
Extended Description
3AXD50000428175 ABB: ACH580 HVAC drive offering has all key features built-in to control fans, pumps and compressors, and more complex equipment like air-handling units and chillers, ensuring smooth, energy-efficient operation of your HVAC systems in normal and mission-critical situations. The ultra-low drive module variant provides ultimate harmonic performance, reaching even less than 3 % THDi, and exceeding the requirements set by low harmonic recommendations.
The drive includes an active supply unit and integrated low harmonic line filter, meaning there is no need for external filters, multi-pulse arrangements or special transformers. Other features include output voltage boost and power factor correction. The built-in features significantly reduce installation time, and the intuitive HVAC specific control panel and help assistants make operation easy. The optional Bluetooth=C2=AE capability enables the commissioning and monitoring of the drive from a distance. The variant comes in IP00 enclosure as standard and for cabinet installation Also, IP20 enclosure is available.
Feature: Built-in active supply unit and integrated low harmonic line filter. Benefit: Reduces harmonic distortion at the source, simplifies installation, and eliminates the need for external filters, trimming cost and footprint. Application: Suitable for large air handling units and chilled water systems where space and reliability are critical. Feature: Ultra-low harmonic performance with THDi <3%. Benefit: Improves power quality, eases compliance with low-harmonic recommendations, and supports higher aggregate loads without additional mitigation. Application: Hospitality projects, data centers, and industrial HVAC loops where harmonics impact upstream equipment. Feature: Output voltage boost and built-in PF correction. Benefit: Enhanced mains power factor and potential energy savings, reducing utility penalties and wiring stress. Application: Fans, pumps, and compressors that experience voltage drops under peak load. Feature: IP00 enclosure standard with IP20 option. Benefit: Flexible deployment in factory floors and control cabinets, enabling quick installation and reduced enclosure fabrication. Application: Retrofit and new-build HVAC installations in plant rooms and equipment housings. Feature: HVAC-focused control panel and help assistants. Benefit: Accelerates commissioning, simplifies operation, and lowers training requirements for maintenance teams. Application: Service workflows for building management integration and remote diagnostics. Feature: Optional Bluetooth capability for remote commissioning and monitoring. Benefit: Faster site startup, reduced on-site visits, and continuous visibility into drive performance. Application: Remote sites and multi-building campuses where on-site access is limited.
Get a Quick Quote for a ABB 3AXD50000428175
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3AXD50000428175?
Enquire Now
FAQs
The 3AXD50000428175 is designed for LV AC HVAC applications and integrates with motors up to 160 kW and 293 A. It features an integrated low harmonic line filter and active supply unit, reducing external hardware needs and simplifying wiring when replacing older drives or upgrading to an ultra-low harmonic solution.
The drive delivers ultra-low harmonic performance with THDi under 3%, supporting 160 kW nominal power and 293 A current. This combination improves mains power quality, reduces interference with other equipment, and helps meet low-harmonic recommendations in HVAC installations.
Yes. The ACH580 ultra-low harmonic variant is specifically suited for HVAC loads such as fans, pumps, compressors, air-handling units, and chillers. Its integrated features and IP-rated enclosures enable reliable operation in demanding facility environments while delivering energy efficiency and smoother control.
The drive ships with IP00 as standard and offers an IP20 enclosure option for cabinet installation. This provides flexibility for different installation environments, from open equipment rooms to controlled cabinet spaces, with protection appropriate to each setting.
Benefits include energy efficiency from PF correction and voltage boost, reduced installation time due to built-in filters and controls, and lower maintenance costs through fewer external components. Optional remote monitoring via Bluetooth further reduces on-site visits and supports proactive performance management.
