ABB 3AXD50000428199 Motors & Drives - Ultra-low harmonic
Part Number: 3AXD50000428199
Quick Summary
ABB 3AXD50000428199 is a LV AC drive module that provides precise motor control for HVAC systems. Engineers face harmonic distortion, costly external filters, and lengthy commissioning when upgrading drives. This ultra-low harmonic variant delivers THDi below 3%, includes an active supply unit and integrated line filter, and offers IP00 standard or IP20 enclosure options to fit cabinet installations. With CE-compliant design and IP-rated enclosures, it supports global deployment for mission-critical HVAC. These features translate into lower total cost of ownership, faster installation, and predictable energy efficiency across HVAC networks.
Product Information
Extended Description
3AXD50000428199 ABB: ACH580 HVAC drive offering has all key features built-in to control fans, pumps and compressors, and more complex equipment like air-handling units and chillers, ensuring smooth, energy-efficient operation of your HVAC systems in normal and mission-critical situations. The ultra-low drive module variant provides ultimate harmonic performance, reaching even less than 3 % THDi, and exceeding the requirements set by low harmonic recommendations.
The drive includes an active supply unit and integrated low harmonic line filter, meaning there is no need for external filters, multi-pulse arrangements or special transformers. Other features include output voltage boost and power factor correction. The built-in features significantly reduce installation time, and the intuitive HVAC specific control panel and help assistants make operation easy. The optional Bluetooth=C2=AE capability enables the commissioning and monitoring of the drive from a distance. The variant comes in IP00 enclosure as standard and for cabinet installation Also, IP20 enclosure is available.
Feature integrated low harmonic line filter and active supply unit → Business impact: dramatically reduces harmonic distortion and eliminates the need for external filters, saving cabinet space and installation time; Application: ideal for HVAC fans, pumps, and compressors where power quality drives performance. Feature output voltage boost and power factor correction → Business impact: enhances motor efficiency, reduces reactive power, and improves overall plant energy use; Application: compressors and large fans in air handling units. Feature HVAC-specific control panel with intuitive help assistants → Business impact: speeds commissioning, reduces configuration errors, and shortens system ramp-up; Application: service technicians and commissioning teams. Feature Bluetooth capability for commissioning and monitoring → Business impact: enables remote setup and fault diagnosis, cutting on-site visits and maintenance costs; Application: remote facilities management and large campus deployments. Feature IP00 enclosure standard with IP20 option → Business impact: flexible installation in machine rooms or cabinets, simplifying compliance and safety; Application: HVAC control panels in varied environments. Feature built-in components (no external multi-pulse or transformers required) → Business impact: lowers total installed cost and reduces maintenance points; Application: retrofit projects and new HVAC drives.
