ABB 3AXD50000428229 LV AC drive module - THDi <3%
Part Number: 3AXD50000428229
Quick Summary
ABB 3AXD50000428229 LV AC drive module controls HVAC fans, pumps, and compressors with ultra-low harmonic performance. Installing legacy drives often introduces harmonic distortion and higher energy costs, but this module minimizes THDi and simplifies commissioning. CE conformity and IP-rated enclosures (IP00 standard; IP20 option) support safe operation in modern facilities. Coupled with built-in features like integrated low-harmonic line filter and control panel guidance, it accelerates HVAC projects while reducing life-cycle costs. This translates into smoother operation, easier remote commissioning via optional Bluetooth, and tangible energy and maintenance savings for facilities teams. Engineers will appreciate the HVAC-focused control panel and quick-start guidance that minimize on-site troubleshooting.
Product Information
Extended Description
3AXD50000428229 ABB: ACH580 HVAC drive offering has all key features built-in to control fans, pumps and compressors, and more complex equipment like air-handling units and chillers, ensuring smooth, energy-efficient operation of your HVAC systems in normal and mission-critical situations. The ultra-low drive module variant provides ultimate harmonic performance, reaching even less than 3 % THDi, and exceeding the requirements set by low harmonic recommendations.
The drive includes an active supply unit and integrated low harmonic line filter, meaning there is no need for external filters, multi-pulse arrangements or special transformers. Other features include output voltage boost and power factor correction. The built-in features significantly reduce installation time, and the intuitive HVAC specific control panel and help assistants make operation easy. The optional Bluetooth=C2=AE capability enables the commissioning and monitoring of the drive from a distance. The variant comes in IP00 enclosure as standard and for cabinet installation Also, IP20 enclosure is available.
Ultra-low harmonic architecture delivers THDi below 3% by combining an integrated low harmonic line filter with an active supply unit. This design minimizes harmonic distortion at the source, reducing the need for external filters, multi-pulse arrangements, or special transformers. The result is simpler cabinet layouts, shorter commissioning times, and improved grid compatibility for HVAC systems including fans, pumps, and compressors in air-handling units and chillers. Operators benefit from steadier voltages and quieter operation, while facilities teams see lower energy penalties and reduced electrical noise in critical spaces. Output voltage boost and built-in power factor correction optimize motor performance during start-up and steady operation, improving torque delivery and reducing current spikes. That translates to lower cable heating, longer motor life, and more reliable equipment in demanding environments. The HVAC-focused control panel and help assistants further shorten commissioning cycles, enabling technicians to tune setpoints quickly and adapt to changing load profiles. Installation and integration advantages are complemented by enclosure options: IP00 standard for primary cabinets and IP20 for harsher environments or cabinet installations. The optional Bluetooth capability enables commissioning and remote monitoring from a distance, reducing site visits and enabling proactive maintenance planning. The drive's compatibility with common HVAC controls and building management systems supports seamless integration into modern facilities, reducing retrofit risk and accelerating project timelines. From a compliance standpoint, built-in filtering and harmonic reduction help meet utility guidelines and building standards while delivering measurable energy efficiency gains. By consolidating filtration, control, and protection into a single unit, total cost of ownership drops through lower hardware counts, easier maintenance, and faster returns on HVAC projects.
Get a Quick Quote for a ABB 3AXD50000428229
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3AXD50000428229?
Enquire Now
FAQs
When installing the ABB 3AXD50000428229 LV AC drive in HVAC cabinets, plan for the IP00 standard enclosure with an available IP20 option to suit the site. Leverage the built-in active supply unit and integrated low harmonic filter to minimize external components. Ensure proper wiring to HVAC controllers, observe cable separation from high-power lines, and confirm compatibility with existing building management systems for seamless operation.
THDi below 3% indicates very low harmonic distortion on the AC input, reducing grid impact and improving overall power quality. This supports compliance with low-harmonic recommendations, lowers supervisory penalties or penalties from utilities in some regions, and can contribute to energy efficiency in HVAC systems by reducing losses and improving power factor through built-in correction features.
Yes. The ACH580-based drive module is designed for HVAC applications, including fans, pumps, compressors, air-handling units, and chillers. It provides HVAC-focused control with built-in energy-saving features, intuitive commissioning, and remote monitoring options, ensuring smooth operation across varying loads and building demands while simplifying integration with existing HVAC controls.
The drive is CE-compliant and offers IP-rated enclosures: IP00 as standard with an IP20 option for cabinet installations. These features support safe operation in typical industrial and commercial HVAC environments and help align with European regulatory requirements and contracting standards for electrical equipment.
The integrated design reduces external filter needs, simplifies installation, and shortens commissioning time, delivering faster project start-up. Energy savings stem from improved power quality and PF correction, while reduced maintenance arises from fewer external components and centralized control. Remote monitoring (Bluetooth option) further lowers on-site visits, supporting predictive maintenance and long-term cost benefits.
