ABB 3AXD50000814404 ACS180 Drive Module - 22 kW IEC
Part Number: 3AXD50000814404
Quick Summary
The ACS180 drive module from ABB delivers precise variable speed control for pumps, fans, and conveyors in industrial plants. Engineers often encounter challenges fitting a capable VSD into compact cabinets without sacrificing reliability. ABB drives are designed to meet CE electrical safety and EMC standards, while enclosure protection and SIL safety concepts are supported across the ABB drive family. This module delivers value by reducing hardware footprint and simplifying system integration, helping you optimize energy use, extend equipment life, and improve process control in industrial automation environments.
Product Information
Extended Description
3AXD50000814404 ABB: The ACS180 is a compact, robust, and adaptable variable speed drive (VSD) for applications such as pumps, fans, compressors, conveyors, winders and mixers.This easy-to-use compact VSD offers excellent performance and quality at superior value with all essential machinery application features embedded. And as a member of ABB=E2=80=99s all-compatible drives portfolio, it shares the same architecture and user interfaces for ease of use.
Feature: Compact LV AC machinery drive module with integrated features. Business Impact: Saves cabinet space and reduces wiring complexity, speeding installation. Application: Ideal for space-constrained pump and fan installations in HVAC and process lines. Feature: 22 kW, 45 A rating. Business Impact: Matches common load profiles with precise speed control, enabling energy savings and smoother operation. Application: Pumps, conveyors, and small to mid-range compressors. Feature: Embedded machinery application features. Business Impact: Cuts BOM size and accelerates commissioning, reducing project risk. Application: Winders, mixers, and packaging lines requiring robust control. Feature: Common architecture and UI with ABB all-compatible drives. Business Impact: Lowers training time and simplifies integration with existing control systems. Application: Plants standardizing on ABB drives for improved maintenance planning. Feature: Robust, reliable design for demanding environments. Business Impact: Minimizes downtime and maintenance costs, improving OEE. Application: Continuous operation in process and utilities plants. Feature: Easy installation and wiring for retrofit and new builds. Business Impact: Reduces installation cost and cabinet revisions. Application: Retrofits to modernize legacy lines or deploy in new automation projects.
Get a Quick Quote for a ABB 3AXD50000814404
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3AXD50000814404?
Enquire Now
FAQs
To install the ACS180 module with an existing ABB drive ecosystem, verify cabinet space with the driver mounted in an appropriate enclosure, connect motor and mains wiring per the ACS180 wiring diagram, and configure parameters using the familiar ABB Drive Control UI. Ensure the 22 kW, 45 A load is within the design envelope, and enable the integrated safety and EMC settings to meet local regulations. Proper commissioning tests should include ramping, motor protection, and feedback loop tuning for pumps, fans, or conveyors.
The ACS180 module provides a 22 kW power rating with a rated current of 45 A, enabling precise speed control for centrifugal and positive-displacement equipment. It supports vector control for smooth starts and dynamic braking, improving process stability and energy efficiency. Applications include pumps, fans, compressors, conveyors, and similar loads where stable torque and speed are critical for performance and energy savings.
Yes. The ACS180 drive module is designed for machinery-driven applications including conveyors and winders. Its compact form factor fits tight spaces, while its robust control algorithms deliver consistent torque, reduced mechanical wear, and improved process harmony. The module’s compatibility with ABB’s drive portfolio ensures a unified interface for programming, diagnostics, and maintenance, making retrofits and expansions straightforward.
ABB drives typically comply with CE marking for safety and EMC, and are designed with enclosure protection considerations that align with common IP-rated expectations in industrial environments. While certifications can vary by region and model, the ACS180 family is developed to support regulatory compliance and safe operation within industrial automation standards, ensuring reliable performance in critical applications.
The ACS180 drive module offers energy efficiency through precise variable speed control, reducing motor current and waste heat in pumps and fans, which lowers operating costs. Its integration with ABB’s all-compatible portfolio simplifies maintenance and reduces spare parts complexity. With robust construction and embedded features, downtime is minimized, yielding a favorable return on investment over the equipment lifecycle.
