ABB 3AXD50000865031 Motors & Drives - UL Type 1 (IP21)
Part Number: 3AXD50000865031
Quick Summary
ABB 3AXD50000865031 is a LV AC irrigation wall-mounted drive designed to optimize pump performance in modern irrigation systems. It delivers compact, low-harmonic operation with unity power factor, helping protect motors and electrical equipment from excessive THiD. Operators often struggle with harmonics and maintenance costs in field installations; this drive meets IEEE 519 requirements while keeping a small footprint and simple serviceability. The unit is available in UL Type 1 (IP21) and supports irrigation-specific software for quick ramps, level and flow control, dry-pump protection, and smart pipe fill. By combining robust protection with versatile fieldbus and I/O options, it delivers reliable control while enabling energy savings and easier integration with existing SCADA or PLC architectures.
Product Information
Extended Description
3AXD50000865031 ABB: The ACQ580-31 ultra-low harmonic (ULH) irrigation wall-mounted drive provides an unprecedented compact design that delivers unity power factor with a 3% or less THiD. By meeting the most stringent requirement of the IEEE519 recommendations, the ACQ580 ULH irrigation drive produces the least amount of harmonic distortion to reduce stress on electrical equipment. The ACQ580-31 irrigation wall-mounted drives are available from 40-150 HP at 460V 3-phase. The drives are available in UL Type 1 (IP21).=20
=20
The irrigation specific software is designed for irrigation applications, enabling easily programmed functions and protections. This innovative programming includes, quick ramps, level control, flow calculations, flow and pressure protection, dry pump protection, soft pipe fill, and others. These drives include fieldbus, I/O modules, and other options available for the ACQ580 irrigation packages.
Feature → Business Impact → Application: The drive delivers unity power factor with THiD ≤ 3%, which reduces electrical stress on transformers and switchgear, cutting maintenance costs and extending equipment life in irrigation pump stations. This aligns with modern water management systems requiring compliant harmonic control and predictable performance for large-scale fields. Application: irrigation pump arrays in farm and municipal systems. Feature → Business Impact → Application: Its compact wall-mounted UL Type 1 (IP21) enclosure simplifies installation in restricted control rooms, saving cabinet space and reducing wiring complexity. This enables faster commissioning and lower installation costs for new irrigation projects. Application: compact control rooms and retrofit installations. Feature → Business Impact → Application: Irrigation-specific software supports quick ramps, level and flow calculations, dry-pump protection, soft pipe fill, and integrated protections, delivering precise water delivery, reduced pump wear, and improved system resilience. Application: pumping stations and irrigation networks. Feature → Business Impact → Application: Fieldbus and I/O modules provide easy PLC/SCADA integration, enabling remote monitoring, alarms, and automated tuning, which lowers on-site visits and improves system uptime. Application: centralized irrigation control and SCADA integration. Feature → Business Impact → Application: The 40–150 HP at 460 V three-phase rating offers scalable capacity for diverse pump sizes, providing a single-stop solution for varying irrigation demands and facilitating standardization across multiple sites. Application: district irrigation systems and agricultural irrigation networks.
