ABB 3AXD50001110956 Servo Motor - 5 Pole-Pairs Design
Part Number: 3AXD50001110956
Quick Summary
ABB 3AXD50001110956 Servo Motor is a high-performance LV AC motor used with the E530 servo drive for precise motion control in automated systems. Engineers often struggle with encoder selection, brake choices, and integrating servos into existing control architectures without downtime. This family supports essential certifications and protective ratings, including CE compliance and IP-rated variants, helping you meet regulatory and environmental demands. Coupled with E530 drive compatibility and ABB service quality, the motor delivers reliable motion control, improved efficiency, and a smoother path to ROI.
Product Information
Extended Description
3AXD50001110956 ABB: The DSM servo motor is a high performance servo motor. It is used together with the E530 servo drive. The DSM servo motor offers various options including: brake, oil seal, and encoder type, which provides flexible choices for customers. The 5 pole-pairs design makes it more compact in structure and effectively reduce the cogging torque.
Feature: The DSM04L-0KWA-302-T0BA0 is a low-voltage LV AC servo motor rated at 0.05 kW with a torque of 0.16 N·m at 220 V. Business Impact: This combination enables precise, energy-efficient motion with strong repeatability and fast response on small axes. Application: Suitable for packaging conveyors, light robotics, and small CNC-type axes where tight control loops are essential. Feature: A 5 pole-pairs design reduces cogging torque for smoother low-speed operation. Business Impact: Improves positioning accuracy and reduces vibration, boosting cycle reliability. Application: Indexing tasks and high-precision pick-and-place. Feature: Full compatibility with ABB E530 servo drive streamlines integration. Business Impact: Shortens commissioning time and lowers integration risk across existing automation architectures. Application: Retrofit projects and new line deployments. Feature: Optional brake, oil seal, and encoder variants offer flexible protection and feedback. Business Impact: Enhances safety, contamination resistance, and feedback fidelity for harsh environments. Application: Machines requiring distributed braking, sealed environments, or diverse encoder options. Feature: Compact form factor and lightweight profile enable easier installation and reduced mounting footprint. Business Impact: Saves machine footprint, reduces cabinet space, and simplifies cabling. Application: Tight automation cells and compact robotics modules.
Get a Quick Quote for a ABB 3AXD50001110956
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3AXD50001110956?
Enquire Now
FAQs
To install ABB 3AXD50001110956 with the E530 drive, mount the motor on a rigid frame and ensure alignment with the load to minimize transverse loads. Use shielded cables for encoder connections and connect the motor harness to the correct E530 drive outputs. Verify brake and encoder options match your control scheme, and configure the drive’s motor parameters (polarity, acceleration, and current limits) for smooth ramping and safe torque delivery.
Key specifications include nominal power of 0.05 kW, nominal torque of 0.16 N·m, 220 V operation, and a 5 pole-pairs design. This combination yields precise positioning and responsive speed control with low cogging torque, especially at low speeds. The motor is designed to work with the E530 drive, enabling predictable torque delivery and repeatable motion for small-axis applications.
Yes. The DSM04L-based motor with 0.05 kW and 0.16 N·m torque is well-suited for packaging conveyors, pick-and-place, and small robotic axes where precise, repeatable motion is required. Its 5 pole-pairs design reduces cogging, enabling smoother indexing and reliable positioning. With encoder and brake options, you can tailor feedback and safety to your application.
This ABB servo motor family is designed to support CE compliance for EU operations, with options that enable protective enclosures and IP-rated configurations typical in industrial environments. Always confirm the exact certification and IP rating for your specific configuration and regional regulatory requirements, especially when integrating into safety-critical systems.
The motor’s high-precision torque, reduced cogging, and compatibility with a single drive ecosystem (E530) help shorten commissioning and reduce downtime. Brake and oil-seal options increase field reliability in harsh environments. Regular inspection of cables, encoder connections, and brake wear will sustain performance, contributing to lower maintenance costs and faster return on investment.
