ABB 3AXD50001122775 Servo Motor - 5 pole-pairs design
Part Number: 3AXD50001122775
Quick Summary
ABB 3AXD50001122775 servo motor delivers precise motion control for automated production lines. When torque, speed stability, and easy drive integration matter, engineering teams face challenges with cogging, tuning time, and compatibility across drives. CE marking is common for EU markets, with optional SIL-capable configurations and IP-rated variants depending on environment and risk. Built as a DSM servo motor, it pairs with ABB’s E530 drive to deliver compact performance, while the 5 pole-pairs design reduces cogging torque for smoother operation. This combination translates to lower downtime, faster commissioning, and scalable deployment across robotics, packaging, and conveyors.
Product Information
Extended Description
3AXD50001122775 ABB: The DSM servo motor is a high performance servo motor. It is used together with the E530 servo drive. The DSM servo motor offers various options including: brake, oil seal, and encoder type, which provides flexible choices for customers. The 5 pole-pairs design makes it more compact in structure and effectively reduce the cogging torque.
Power and voltage alignment: The DSM servo motor delivers 1 kW at 380 V, a balance that suits mid-range automation tasks while keeping wiring and cooling requirements manageable. Business impact: This enables reliable performance on conveyors, pick-and-place modules, and machine centers without over-sizing downstream drives. Application: Ideal for moderate-load applications in packaging lines and material handling. Cogging torque reduction: The 5 pole-pairs design minimizes torque ripple, delivering smoother motion and higher path precision in high-speed pick-and-place and robotic cell applications. Business impact: Improves repeatability and reduces wear on mechanical components, lowering maintenance costs. Application: Widely suited for precise motion control in food and beverage packaging, electronics assembly, and labeling systems. Drive compatibility: Seamless integration with ABB E530 servo drive supports simplified commissioning and centralized control. Business impact: Faster setup, reduced commissioning time, and a unified control platform. Application: Preferred in integrated automation architectures where fleet management and diagnostics matter. Flexible options: Brake, oil seal, and encoder-type options address environmental and lifecycle requirements. Business impact: Enables installation in dusty or damp environments and extends motor life through tailored protection. Application: Suitable for conveyors in wash-down areas, packaging lines, and automated sorting systems. Installation and efficiency: LV AC operation with compact geometry reduces panel space and wiring complexity. Business impact: Cuts installation time and energy usage, improving total cost of ownership. Application: Ideal for OEMs and integrators delivering turnkey automation solutions.
Get a Quick Quote for a ABB 3AXD50001122775
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 3AXD50001122775?
Enquire Now
FAQs
The motor is designed for direct pairing with the ABB E530 servo drive. Start with confirming 380 V supply, mounting orientation, and encoder wiring per the drive’s configuration guide. Use standard servo cables, ensure motor-to-drive impedance matches, and configure the drive gains in small increments. The 5 pole-pairs design helps balance torque and smoothness, minimizing tuning time during commissioning and reducing the risk of cogging-related disturbances.
The motor provides Pn of 1 kW and Tn of 3.18 N·m at 380 V, with a 5 pole-pairs configuration. These specs suit mid-range automation tasks including conveyors and pick-and-place modules. When selecting for a specific cycle rate, verify your load inertia and adjust drive tuning to optimize velocity and torque bandwidth for reliable, repeatable motion.
Yes. Its 1 kW power rating, 3.18 N·m torque, and 5 pole-pairs design deliver precise control and reduced cogging, which are essential for packaging lines and robotics. The motor’s compatibility with the E530 drive enables synchronized motion across multiple axes, enhancing line throughput and repeatability. Flexible encoder options support various feedback needs in complex robotics tasks.
CE marking is commonly pursued for EU markets, supporting safety and environmental compliance. Depending on installation, you may also consider SIL-capable configurations for safety-related control and IP-rated variants for harsh environments. Always verify the specific configuration with your ABB distributor to ensure your environment meets all relevant regulatory and safety requirements.
The motor’s compact LV AC design and E530 compatibility reduce integration time and panel footprint, leading to faster commissioning and lower startup costs. Reliability is enhanced by configurable brake and encoder options, which support longer life in demanding environments. The result is improved uptime, predictable maintenance planning, and a favorable total cost of ownership over the motor’s life cycle.
