ABB 3GFT162744-SDB Motors & Drives High Dynamic IP23
Part Number: 3GFT162744-SDB
Quick Summary
ABB M3FT 160D 4 high dynamic motor delivers reliable drive performance for heavy-duty industrial lines. Engineers often face efficiency losses and downtime when ambient conditions, space constraints, or mounting options limit performance. This unit features IP23 protection, IC LH insulation, and IE1 efficiency data—92.8% at 100% load on 50 Hz and 93.6% on 60 Hz—supporting regulatory compliance and predictable energy use. Its aluminum frame, 4-pole design, and compatible IM mounting simplify installation and service, while a 370 V operating voltage and 1000 m altitude rating extend operational flexibility in modern plants.
Product Information
ABB Type Designation
M3FT 160D 4
Invoice Description
M3FT 160D 4
Product Name
High dynamic performance motors
Product Type
3FTB__M3FT__HDP__IP23_
Made To Order
No
Minimum Order Quantity
1 piece
Order Multiple
1 piece
Selling Unit of Measure
piece
Country of Origin
Finland (FI)
Customs Tariff Number
85015381
Electrical Data
Temperature Class Default
--
Motor Operational Voltage
370 V
Altitude
1000 m
Ambient Temperature
40 °C
IC Class
IC06
IE Class Data (50 Hz)
IE Class IE1 | Full Load (100%) 92.8 % | Partial Load (75%) 93.4 % | Partial Load (50%) 93.3 %
IE Class Data (60 Hz)
IE Class IE1 | Full Load (100%) 93.6 % | Partial Load (75%) 93.8 % | Partial Load (50%) 93.2 %
IP Class
IP23
Insulation Class
ICLH
Direction of Rotation
Both sides
Number of Poles (High)
4
Two Speed Motor
No
Type of Duty
S9
Voltage Code
D
Frame Material
Aluminum
Frame Size
160
Bearing
6312-2Z
Bearing NDE
6312-2Z
IM Class
IMB35 IM2001
Terminator Box Location
N-End right side
Package Level 1 Units
0 pallet (lift)
Product Net Weight
300 kg
Gross Weight
310 kg
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
UNSPSC
26101100
Feature: High dynamic performance with a 4-pole design and 370 V operation. Business impact: Provides rapid torque response and stable speed control, improving line throughput and reducing cycle times. Application: Ideal for conveyors, packaging lines, and processing equipment requiring precise speed control. Feature: Aluminum frame and IM mounting compatibility. Business impact: Reduces weight, simplifies retrofits, and accelerates installation while maintaining robustness. Application: Fits standard ABB drive ecosystems and existing mounting patterns in general industry. Feature: IE1 efficiency metrics with transparent performance data. Business impact: Lowers energy costs and supports compliance reporting across 50 Hz and 60 Hz operation. Application: Continuous-duty lines with predictable energy usage in manufacturing plants. Feature: IP23 protection and robust bearings. Business impact: Enhances reliability in semi-enclosed environments and reduces maintenance cycles. Application: Suitable for general manufacturing, material handling, and processing lines. Feature: S9 duty rating and bearing life. Business impact: Enables reliable operation under steady workloads with occasional overload, extending uptime. Application: Industrial automation tasks including machine tools and packaging lines. Feature: Environmental and compatibility safeguards. Business impact: 370 V operation, ambient 40 °C, altitude up to 1000 m, and N-End termination box location support flexible integration. Application: New installs and upgrades in varied plant environments.
