ABB 7161.170 Mounting Plate - CE Compliant, ETIM EC000013
Part Number: 7161.170
Quick Summary
ABB 7161.170 Mounting Plate is a compact mounting solution for SM components used in control panels. Engineers often struggle to source base plates that fit flush-mounted layouts without adding complexity or compromising safety. This part carries CE declarations, ETIM EC000013 classification, and REACH compliance, aligning with European regulatory requirements. The combination of durable Duroplast material, oyster white color (RAL 1013), and a vertical mounting orientation delivers a robust, visually consistent solution for enclosures and electrical infrastructure, while simplifying inventory and maintenance workflows for panel builders and system integrators.
Product Information
Extended Description
7161.170 ABB: Mountingplate for SM components
Model Number
2-fold
Accessory Type
Mounting Plate
Product Type
Mounting cover
Mounting Orientation
Vertical
Shape
Double
Surface Finishing
Surface protection: Untreated
Material
Material quality: Duroplast | Material: Plastic
RAL Number
RAL 1013 - Oyster White
Color
Cream white (electro white)
Number of Batteries
0
REACH Declaration
REACH Declaration ABB BV, Ede
REACH Information
False - does not contain substances > 0.1 mass percentage
REACH Date
20230911
Conflict Minerals Reporting Template (CMRT)
Conflict Minerals Reporting Template
WEEE Category
Product Not in WEEE Scope
Environmental Information
Declaration regarding the REACH - Regulation
Product Net Width
56.000 mm
Product Net Height
40.000 mm
Product Net Depth / Length
65.000 mm
Product Net Weight
0.029 kg
Package Level 1 Units
bag 25 piece
Package Level 1 Gross Weight
0.785 kg
Declaration of Conformity - CE
Declaration regarding the REACH - Regulation
Data Sheet, Technical Information
WebCatalog_Consumer Units and Junction Boxes
ETIM 8
EC000013 - Base plate for flush mounted installation
ETIM 9
EC000013 - Base plate for flush mounted installation
eClass
V11.0 : 27144010
Object Classification Code
Not applicable
Feature → Business Impact → Application: The mounting plate uses Duroplast plastic, delivering a lightweight yet sturdy base that reduces overall panel weight and handling effort, improving installation speed and worker safety on the shop floor. Application: Ideal for OEMs and panel builders deploying SM components in enclosures where weight saving and ease of handling matter most. Feature → Business Impact → Application: The vertical mounting orientation with a double (2-fold) plate design enables compact, flush-mounted installations that maximize available space inside control cabinets, boosting cavity efficiency and reducing interference with adjacent components in dense assemblies. Application: Suitable for vertical layouts in compact enclosures. Feature → Business Impact → Application: The precise dimensions (56 mm width, 40 mm height, 65 mm depth) ensure consistent alignment with standard mounting patterns, reducing rework and mounting errors in high-volume production. Application: Works with standardized panels and ABB SM component stacks. Feature → Business Impact → Application: Color and surface finishing (Cream white, untreated) provide clear visibility and corrosion resistance in dry indoor environments, supporting uniform aesthetics and long-term durability in electrical infrastructure. Application: Best for indoor control panels and enclosure interiors. Feature → Business Impact → Application: Regulatory compliance like REACH, CMRT, and CE declarations minimize risk during audits and supplier qualification, improving procurement confidence and reducing compliance costs. Application: Beneficial for commodity sourcing in manufacturing plants and automation projects. Feature → Business Impact → Application: Packaging (bag 25 pieces) enables efficient bulk ordering and streamlined stocking for high-volume assembly lines, minimizing downtime and optimizing warehouse space. Application: Ideal for distributors and systems integrators managing large BOMs.
