ABB 7B1217W Motor - UR Certified, 1PH 60Hz
Part Number: 7B1217W
Quick Summary
ABB 7B1217W motor provides reliable single-phase power for compact industrial grinders, buffers, lathes, and belt sanders. With 2 HP at 1800 RPM and a 60 Hz supply, this unit delivers steady torque for continuous operation in demanding shop-floor environments. The design addresses space constraints, quick installation, and minimized maintenance downtime. It carries UR certification and UL/CSA horsepower alignment, reinforcing compliance for multiple markets while offering a straightforward mounting solution. Stocked availability across multiple warehouses supports faster project timelines and predictable uptime, a valuable asset for tool rooms and light manufacturing lines. The 40 °C ambient rating and TENV enclosure further enhance rugged performance in practical applications.
Product Information
Extended Description
7B1217W ABB: 2HP,1800RPM,1PH,60HZ,3634L,GRND
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,1800RPM,1PH,60HZ,3634L,GRND
Ambient Temperature
40 °C
Brand / Label
Baldor-Reliance®
Catalog Number
1217W
Certification Agency
UR
Country of Origin
United States (US)
Customs Tariff Number
85015230
Dimension Diagram
G2LY0119: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
1217W
Gross Volume
21929.457 in³
Gross Weight
253 lb
Horsepower Rating UL/CSA
2.000 Hp
IDEA Granular Category Code (IGCC)
1329 >> Single phase motor AC
Insulation Class
B
Invoice Description
2HP,1800RPM,1PH,60HZ,3634L,GRND
Made To Order
No
Medium Description
1 Phase, TENV Enclosure, (1217W)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Mounting Orientation
Horizontal
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp
Product Name
Grinders/Buffers/Lathes/Belt Sander
Product Net Depth / Length
41.313 in
Product Net Height
28.5 in
Product Net Weight
253 lb
Product Net Width
18.625 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
20 A | 10 A
Rated Speed
1800 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
1.25 in
Short Description
1 PH, TENV,
Standards
Other
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
UNSPSC
26101116
Voltage Rating
115 V | 230 V
Feature → 2 HP, 1800 RPM, 1PH, 60 Hz provides robust starting torque and stable speed, enabling predictable performance for small machine tools. Business Impact → Improves cycle times and reduces throughput bottlenecks in grinding, buffing, and lathing operations. Application → Ideal for compact grinders, buffers, and belt sanders in repair shops and light manufacturing facilities. Feature → Foot-mounted, horizontal mounting with 1.25 in shaft diameter supports easy installation and alignment. Business Impact → Cuts installation time and lowers mounting variability, decreasing setup errors. Application → Simple retrofit into existing tool layouts with standard bases. Feature → Enclosure Type TENV and ambient rating of 40 °C deliver rugged, low-maintenance operation. Business Impact → Extends service intervals and reduces unplanned downtime. Application → Suitable for open workshops and semi-enclosed industrial environments. Feature → Voltage rating 115 V | 230 V and 4-pole design delivering 1800 r/min synchrony. Business Impact → Flexible power options and reliable performance under varying loads. Application → Fits diverse electrical infrastructures and continuous-duty tasks in light industrial lines. Feature → Certification and branding notes (UR, UL/CSA horsepower) provide confidence for multi-region compliance. Business Impact → Simplifies procurement and regulatory cross-checks, accelerating project approvals. Application → Supports global supply chains and multinational deployment in machine tools and process lines. Feature → Stocked at multiple warehouses (US, China, etc.). Business Impact → Reduces lead times, improving project scheduling and on-site commissioning. Application → Critical for OEMs and service teams needing rapid replacement parts during maintenance windows.
