ABB 7B1453 Electric Motor - 7.5HP, 3-Phase, CSA Cert
Part Number: 7B1453
Quick Summary
The ABB 7B1453 electric motor provides robust, energy-efficient power for 3-phase industrial drives. This 7.5 HP, 50/60 Hz motor is designed for continuous operation on conveyors, pumps, and processing lines. In practice, engineers struggle with uptime, cross-region compatibility, and long lead times when sourcing motors that meet global standards. The 7B1453 carries CSA certification and a TE NV enclosure, plus a 208/230/460 V rating, enabling seamless integration across North American and international facilities. Foot-mounted, horizontal installation and a 2-pole design simplify retrofits and new equipment builds, while the steel frame ensures durability in challenging environments. Stocked at multiple warehouses, it supports fast procurement and predictable project planning.
Product Information
Extended Description
7B1453 ABB: 7.5HP,3000/3600RPM,3PH,50/60HZ,3735M
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
7.5HP,3000/3600RPM,3PH,50/60HZ,3735
Ambient Temperature
40 °C
Brand / Label
Baldor-Reliance®
Catalog Number
1453
Certification Agency
CSA
Country of Origin
United States (US)
Customs Tariff Number
8460908020
Design
B
Dimension Diagram
G4LY0117: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt | Undefined Efficiency
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
50 Hz | 60 Hz
Global Commercial Alias
1453
Gross Volume
0 in³
Gross Weight
223 lb
Horsepower Rating UL/CSA
7.500 Hp
IDEA Granular Category Code (IGCC)
1325 >> General purpose motor AC
Insulation Class
B
Invoice Description
7.5HP,3000/3600RPM,3PH,50/60HZ,3735M
Made To Order
No
Medium Description
3 Phase, TENV Enclosure, (1453)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Mounting Orientation
Horizontal
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
7.50 Hp
Product Name
Grinders/Buffers/Lathes/Belt Sander
Product Net Depth / Length
0 in
Product Net Height
0 in
Product Net Weight
223 lb
Product Net Width
0 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
20 A
Rated Speed
3000 r/min | 3600 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
1.25 in
Short Description
3 PH, TENV,
Standards
Other
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3000 r/min | 3600 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
208 V | 230 V | 460 V
Feature: 7.5 HP, 3-phase, 50/60 Hz, 208/230/460 V. Business Impact: Provides flexible electrical supply compatibility across regions, reducing part substitutions and re-wiring during upgrades. Application: Suitable for conveyors, pumps, and general purpose machinery in manufacturing lines. Feature: TE (Totally Enclosed Non-Ventilated) enclosure (TENV). Business Impact: Protects windings from dust and moisture in harsh plant environments, lowering maintenance costs. Application: Environments with moderate cleanliness requirements and dust exposure. Feature: Foot-mounted, horizontal mounting with a 2-pole design. Business Impact: Simplifies retrofit projects and stock-keeping, enabling faster installation and serviceability. Application: Retrofit of legacy equipment and new line deployments. Feature: Wide voltage and frequency range (208/230/460 V; 50/60 Hz). Business Impact: Supports multi-region projects without rewiring or specialty variants, reducing lead times. Application: Global installations and cross-site operations. Feature: Insulation Class B and NEMA Design Code B. Business Impact: Delivers reliable insulation performance and predictable torque characteristics, minimizing risk of insulation failures. Application: Continuous duty in standard manufacturing sites. Feature: 223 lb weight and steel frame. Business Impact: Indicates structural robustness and ease of handling during installation and maintenance. Application: Heavy-duty industrial environments with rigorous vibration and load profiles. Long-tail keywords integrated: 7.5 HP electric motor, 3-phase industrial motor, foot-mounted motor, TENV enclosure motor, CSA certified motor, 208-230-460V motor, 50/60 Hz motor, two-pole induction motor, continuous duty motor, ISO/UL ready motor.
