ABB 7B248-151TD 1 Ph TEFC Motor - UL Certified
Part Number: 7B248-151TD
Quick Summary
ABB 7B248-151TD is a 1-phase TEFC motor for grinders and lathes in light industrial settings, designed for reliable, compact drive. Engineers often contend with downtime from undersized drives and long lead times; this unit ships ready-to-run to simplify procurement and commissioning. It carries UL certification, ETIM 7 EC001851 designation, and a TEFC enclosure for rugged environments. With dual-voltage operation and a compact footprint, it delivers reliable performance while reducing installation time and total cost. Stocked at multiple warehouses across the US and China for instant availability, it supports scalable automation projects. This combination helps maintenance teams shorten downtime and accelerate capital projects.
Product Information
Extended Description
7B248-151TD ABB: 28L 2P GRNDR PIVOTAL
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
28L 2P GRNDR PIVOTAL
Ambient Temperature
40 °C
Brand / Label
Baldor-Reliance®
Catalog Number
248-151TD
Certification Agency
UL
Country of Origin
United States (US)
Customs Tariff Number
8460908080
Design
L
Dimension Diagram
B2LY0005: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
248-151TD
Gross Volume
13239.046 in³
Gross Weight
95 lb
Horsepower Rating UL/CSA
1.500 Hp
IDEA Granular Category Code (IGCC)
1329 >> Single phase motor AC
Insulation Class
B
Invoice Description
28L 2P GRNDR PIVOTAL
Made To Order
No
Medium Description
1 Phase, TEFC Enclosure, (248-151TD)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Mounting Orientation
Horizontal
NEMA Design Code
L
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1.50 Hp
Power Factor
82 %
Product Name
Grinders/Buffers/Lathes/Belt Sander
Product Net Depth / Length
26.5 in
Product Net Height
32.625 in
Product Net Weight
95 lb
Product Net Width
15.313 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
15 A | 7.5 A
Rated Efficiency
70 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Short Description
1 PH, TEFC,
Standards
Other
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101116
Voltage Rating
115 V | 230 V
Feature: Dual-voltage operation (115 V / 230 V) enables seamless integration with existing electrical distributions, reducing wiring changes and spare-part complexity. Business Impact: Simplifies procurement across multiple job sites and lowers overall installed costs. Application: Ideal for 1-phase grinders, buffers, and small machine tools where power flexibility matters. The motor’s long-term reliability translates to reduced downtime and predictable performance in workshop environments. Feature: TEFC enclosure with a steel frame delivers robust protection against dust, splash, and incidental contact. Business Impact: Extends service life in dirty or workshop conditions and supports compliance with general purpose motor standards in non-hazardous areas. Application: Suitable for belt sanders and light metalworking equipment in open-floor plans. The rugged enclosure also eases compliance audits and maintenance planning. Feature: Direct-on-line starting and 60 Hz operation provide straightforward commissioning with minimal startup components. Business Impact: Lowers initial investment by removing specialty soft starters for small-load applications and reduces energy waste during ramp-up. Application: Commonly deployed in retrofit projects where existing 1-phase lines must drive compact tools. Feature: Stocked-at-warehouses and zero-day lead-time availability improve project velocity and spare parts resilience. Business Impact: Shortens time-to-value for automation upgrades and minimizes production disruption. Application: Critical for retrofit programs and new line installations needing rapid delivery. Feature: Rated Power 1.5 HP with 2 poles and 3450 r/min (60 Hz) delivers reliable torque for continuous duty in light-industrial tasks. Business Impact: Supports consistent cutting, grinding, or polishing cycles with predictable performance. Application: Well-suited for small-capacity grinders, lathes, and buffers, enabling smoother tool operation and better process control. Feature: Insulation Class B and 70% rated efficiency with a 82% power factor offer balanced energy use and heat management. Business Impact: Lowers operating costs over lifetime and reduces cooling requirements in compact enclosures. Application: Aligns with standard facilities’ energy management programs while preserving task-specific performance.
