ABB 7B34-2780-872 Pump Motor - TEFC Enclosure CSA UR Certified
Part Number: 7B34-2780-872
Quick Summary
Pump motor ABB 7B34-2780-872 powers compact pump systems in industrial processes. This 0.5 HP, 230 V three-phase unit is designed for reliable, long-life operation in demanding environments. Users often struggle to find a motor that fits both a tight frame and exact voltage options while meeting regulatory and safety standards. This model delivers TEFC protection with NEMA compliance and CSA | UR certification, helping maintenance teams simplify procurement and maintenance. With 230/460 V dual-voltage capability and a 60 Hz rating, the motor supports flexible installations, while the Baldor-Reliance branding signals compatibility with a wide range of pumps, belts, and coupling configurations for optimized plant-wide efficiency.
Product Information
Extended Description
7B34-2780-872 ABB: Pump Motor 0.50 Hp 230 V (34-2780-872)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.5HP,1725RPM,3PH,60HZ,56YZ,3416M,TE
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
34-2780-872
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Drive End Flange Type
SAE Pump
Efficiency Level
Not Regulated / Exempt | Undefined Efficiency
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
34-2780-872
Gross Volume
1400.25 in³
Gross Weight
23 lb
Insulation Class
B
Invoice Description
.5HP,1725RPM,3PH,60HZ,56YZ,3416M,TEFC,F1
Made To Order
No
Medium Description
Pump - Misc, 0.5 HP, 1800 RPM, Frame Size 56Yz, SaePump Mounting, 3 Phase, TEFC Enclosure, 230/460 V, 60 Hz (34-2780-872)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56YZ
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
0.50 Hp
Power Factor
63 %
Product Name
Pump - Misc
Product Net Depth / Length
13.813 in
Product Net Height
9.375 in
Product Net Weight
23 lb
Product Net Width
10.813 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
2 A | 1 A
Rated Efficiency
74 %
Rated Speed
1725 r/min
Selling Unit of Measure
piece
Service Factor
1.25
Short Description
0.5 HP, 1800 RPM, Frame Size 56Yz, SaePump, 3 PH, TEFC, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
The TEFC enclosure protects the windings from dust, moisture, and typical shop-floor contaminants, delivering higher MTBF and lower maintenance costs. In real-world pumping installations, this translates to fewer unscheduled stops and longer intervals between service, especially in dusty or humid environments. Applications include process pumps, water handling, and HVAC circulation where continuous operation is essential. The 0.50 HP output at 1725 rpm in a 3-phase design provides sufficient pump head while keeping energy usage proportional to load, reducing operating costs. This motor is well-suited for small-bore pumping, circulation, and lift tasks in manufacturing lines and packaging machinery. Dual voltage rating of 230 V / 460 V and 60 Hz compatibility simplifies retrofit projects and international installations, reducing wiring complexity and stock variety. It fits a 56YZ frame with foot-mounted, horizontal mounting, and standard Baldor-Reliance footprints to streamline installation and replacements.
