ABB 7B34-5104-3226 Pump Motor - TEFC IE3 Premium
Part Number: 7B34-5104-3226
Quick Summary
ABB 7B34-5104-3226 Pump Motor is a 1 HP, 230 V three-phase motor designed for centrifugal and jet pump drives in water-transfer and process systems. It addresses the common challenge of balancing energy efficiency with reliability by pairing IE3 Premium efficiency with a rugged TEFC enclosure. With CSA and UR certifications and a 60 Hz rating, the design meets US and international standards while enabling straightforward replacement and routine maintenance. The 56J frame, C-face mounting, and dual-voltage compatibility (230/460 V) support flexible installation across multiple pump configurations, driving lower operating costs and improved uptime. In short, it delivers energy savings, dependable performance, and a strong total-cost-of-ownership profile for industrial pumping applications.
Product Information
Extended Description
7B34-5104-3226 ABB: Pump Motor 1 Hp 230 V (34-5104-3226)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,3450RPM,3PH,60HZ,56J,3420M,TEFC
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
34-5104-3226
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Drive End Flange Type
C-Face
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
34-5104-3226
Gross Volume
2110.969 in³
Gross Weight
28 lb
Insulation Class
B
Invoice Description
1HP,3450RPM,3PH,60HZ,56J,3420M,TEFC,F1,N
Made To Order
No
Medium Description
56J Jet Pump, 1 HP, 3600 RPM, Frame Size 56J, C-Face Mounting, 3 Phase, 230/460 V, 60 Hz (34-5104-3226)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
56J
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
82 %
Product Name
56J Jet Pump
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
28 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.2 A | 1.6 A
Rated Efficiency
77 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.40
Shaft Diameter
0.63 in
Short Description
1 HP, 3600 RPM, Frame Size 56J, C-Face, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature → Business Impact → Application: IE3 Premium Efficiency rating reduces energy consumption in continuous pumping operations, delivering meaningful operating-cost savings and improved power usage effectiveness in 1 HP pump systems. Application: water transfer, irrigation, and process pumping where energy efficiency is critical. Feature → Business Impact → Application: TEFC enclosure provides superior protection against dust, moisture, and wash-down environments, extending winding life and reducing maintenance cycles. Application: outdoor or damp plant areas, mining, and municipal pumping stations. Feature → Business Impact → Application: 56J frame with C-face mounting and horizontal, footless base simplifies retrofits and new installations, enabling quick alignment with existing base plates and easy bolting to pump couplings. Application: retrofit projects and new-build pump trains using Baldor-Reliance 56J components. Feature → Business Impact → Application: Direct-on-line starting capability lowers upfront drive hardware costs while maintaining robust starting torque for common 2-pole, 3-phase loads. Application: simple pump starts at 60 Hz, 230 V service. Feature → Business Impact → Application: dual-voltage (230/460 V) operation supports global procurement and simplifies stock management, reducing spare-part complexity. Application: multinational plants and varied electrical grids. This combination of protective enclosure, efficiency, and installation flexibility translates to measurable gains in uptime, energy cost avoidance, and simplified maintenance planning for pump-driven processes.
Get a Quick Quote for a ABB 7B34-5104-3226
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7B34-5104-3226?
Enquire Now
FAQs
This motor supports 3-phase power at 230 V or 460 V with a 60 Hz service, enabling flexible integration into US and international pump systems.
Yes. The motor is designed for direct-on-line starting on 230 V, 3-phase systems, offering robust starting torque for typical 2-pole pump loads while keeping installation simple and cost-effective.
The unit features C-face mounting with horizontal orientation and a footless base, allowing straightforward retrofit with existing flanges and base plates.
It carries IE3 Premium efficiency, NEMA design B, and CSA | UR certification, aligning with US and international compliance requirements for quality and reliability.
Key specs include 1 HP, 3450 r/min (synchronous 3600 r/min), service factor 1.40, and 77% efficiency. These translate to lower energy costs, improved uptime, and faster payback in pumping installations.
