ABB 7B340 Motor - 0.25/0.06HP Dual-Speed 1P 60Hz
Part Number: 7B340
Quick Summary
ABB 7B340 motor is a compact, dual-speed, single-phase motor designed for small machines and service shops that demand flexible speed control. By combining two operating speeds in one package, it reduces inventory and simplifies drive selection for equipment like grinders, buffers, lathes, and belt sanders. This design addresses the common challenge of choosing a single-speed motor that can perform multiple operations without swapping components. The unit carries CSA and UR certifications, supporting safe operation in North American facilities, and a TENV enclosure that protects against dust and incidental exposure. With 115 V, 60 Hz power compatibility, and a robust steel frame, it delivers reliable performance while enabling faster ROI for light industrial applications.
Product Information
Extended Description
7B340 ABB: .25/.06HP,3600/1800RPM,1PH,60HZ,3424S
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.25/.06HP,3600/1800RPM,1PH,60HZ,342
Ambient Temperature
40 °C
Brand / Label
Baldor-Reliance®
Catalog Number
340
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
8460908020
Dimension Diagram
L4LY0024: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
340
Gross Volume
2200.078 in³
Gross Weight
31 lb
Horsepower Rating UL/CSA
0.060 Hp | 0.250 Hp
IDEA Granular Category Code (IGCC)
1323 >> Multispeed motor AC
Insulation Class
B
Invoice Description
.25/.06HP,3600/1800RPM,1PH,60HZ,3424S
Made To Order
No
Medium Description
1 Phase, TENV Enclosure, (340)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Mounting Orientation
Horizontal
Number of Phases
1
Number of Poles
2P | 4P
Number of Poles (High)
4
Number of Poles (Low)
2
Number of Speeds
two_speed
Order Multiple
1 piece
Output Power
0.25 Hp | 0.06 Hp
Product Name
Grinders/Buffers/Lathes/Belt Sander
Product Net Depth / Length
18.625 in
Product Net Height
11.25 in
Product Net Weight
31 lb
Product Net Width
10.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
2.9 A | 2 A
Rated Speed
1800 r/min | 3600 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
0.38 in
Short Description
1 PH, TENV,
Standards
Other
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min | 3600 r/min
Type of Duty
Continuous
UNSPSC
26101110
Voltage Rating
115 V
Dual-speed capability (1800 r/min low speed and 3600 r/min high speed) provides broad process control in a single motor, reducing parts inventory and installation time. This translates to measurable efficiency gains on shop floor conveyors, grinders, and small lathes as throughput improves without changing hardware. The 115 V, 1-phase, 60 Hz design matches standard facility power, lowering wiring costs and simplifying integration with existing controls. The TENV enclosure and insulation class B enhance reliability in typical workshop environments, minimizing dust ingress and thermal stress to extend motor life. Foot-mounted orientation and a 0.38 in shaft diameter support straightforward installation, alignment, and compatibility with common belts and pulleys, while 2P/4P pole configurations offer flexibility for different load profiles. CSA and UR certifications underpin compliance and risk management, easing procurement and commissioning for industrial buyers. Stocked at multiple warehouses and backed by a straightforward warranty framework, this motor supports reduced downtime and faster project realization in grinders, buffing stations, and small machine tools.
Get a Quick Quote for a ABB 7B340
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7B340?
Enquire Now
FAQs
Yes. The 7B340 is a 115 V, 60 Hz, single-phase motor designed for direct-on-line starting. It fits standard shop power and typical belt-driven or pulley-laden equipment, simplifying installation and reducing the need for specialty transformers or controls. This compatibility supports quick retrofits and minimal wiring changes during modernization projects.
The motor provides two speeds: 1800 r/min (low) with 0.06 HP and 3600 r/min (high) with 0.25 HP. The current draw is approximately 2 A on the low-speed setting and 2.9 A on the high-speed setting, enabling appropriate drive sizing for light-duty grinders, buffers, lathes, or belt sanders without overloading the circuit.
This dual-speed motor is well-suited for grinders, buffers, lathes, and belt sanders in small to mid-size workshops. Its 1-phase, 60 Hz operation and compact footprint support integration into existing benches or compact tool stations, while the two-speed capability provides operational versatility across finishing and material removal tasks.
The ABB 7B340 carries CSA and UR certifications, indicating compliance with recognized safety standards for North American operation. This, combined with a 40 °C ambient rating and a TENV enclosure, supports safe installation in typical workshop environments and simplifies procurement for regulated projects.
Maintenance is straightforward due to the simple, direct-on-line single-phase design and standard 115 V supply. The dual-speed capability reduces the need to stock multiple motors, cutting both purchase and maintenance costs. Stocked availability across warehouses minimizes downtime, while the compact footprint and robust steel frame contribute to longer service intervals and a faster return on investment for small machine upgrades.
