ABB 7B34F775R075G1 Condensor Fan - 0.5HP, 115V, NEMA
Part Number: 7B34F775R075G1
Quick Summary
ABB 7B34F775R075G1 Condensor Fan delivers reliable 0.5 HP cooling for open-enclosure condensers in HVAC and refrigeration systems. When downtime is costly, engineers need a direct replacement with fast lead times and consistent airflow. It carries key standards such as NEMA compliance and CSA/UR listings, helping satisfy regulatory requirements in regulated environments. With 115 V single-phase operation at 60 Hz and a 48YZ frame, it integrates smoothly with Baldor-Reliance installations while offering predictable performance. Fast stock across multiple warehouses further supports project timelines and reduces total cost of ownership.
Product Information
Extended Description
7B34F775R075G1 ABB: Condensor Fan 0.5 Hp 115 V (34F775R075G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.5HP,3300RPM,1PH,60HZ,48YZ,3424C,OP
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
34F775R075G1
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85013100
Drive End Flange Type
Standard
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
34F775R075G1
Gross Volume
19330.126 in³
Gross Weight
29 lb
Insulation Class
B
Invoice Description
.5HP,3300RPM,1PH,60HZ,48YZ,3424C,OPEN,F1
Made To Order
No
Medium Description
Condensor Fan, 0.5 HP, 3000 RPM, Frame Size 48Yz, Standard Mounting, 1 Phase, 115 V, 60 Hz (34F775R075G1)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
48YZ
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
0.5 Hp
Power Factor
99 %
Product Name
Condensor Fan
Product Net Depth / Length
44.25 in
Product Net Height
11.688 in
Product Net Weight
29 lb
Product Net Width
37.375 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.7 A
Rated Efficiency
70 %
Rated Speed
3300 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.38 in
Short Description
0.5 HP, 3000 RPM, Frame Size 48Yz, Standard, 1 PH, 115 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
Voltage Rating
115 V
Feature: 0.5 HP, 115 V, 60 Hz, single-phase operation; Business Impact: straightforward wiring and dependable startup, enabling quick drop-in replacement; Application: condenser fans in HVAC and refrigeration setups. Feature: Frame 48YZ and open enclosure with horizontal mounting (F1); Business Impact: flexible installation and compatibility with standard Baldor-Reliance mounts; Application: retrofit and new builds using common frame sizes. Feature: Rated efficiency 70% and current 4.7 A; Business Impact: lower operating costs and energy efficiency for continuous-duty cooling; Application: energy-conscious industrial condensers and commercial chillers. Feature: Bearings 6203 Ball, shaft 0.38 in, direct on line starting; Business Impact: reduced maintenance and robust start-up performance; Application: durable operation in harsh environments. Feature: Stocked across multiple warehouses with 0 day lead time and 29 lb weight; Business Impact: fast fulfillment and simplified logistics; Application: rapid deployment for projects with tight timelines.
