ABB 7B34G205W81G1 General Purpose HVAC - 1PH 115V CSA UR
Part Number: 7B34G205W81G1
Quick Summary
ABB 7B34G205W81G1 is a general purpose HVAC motor engineered for 0.75 HP, single‑phase operation in air handling and ventilation equipment. This design addresses common field challenges such as limited space, difficult alignment, and inconsistent airflow by delivering a compact 56-frame footprint, horizontal mounting, and a resilient base that dampens vibration. The unit carries CSA and UR listings and aligns with NEMA design guidance, helping teams meet safety and reliability standards across regulatory environments. For OEMs and maintenance teams, predictable start-up, easy wiring, and robust bearings translate into reduced downtime and simplified spares management. In short, it combines proven ABB build quality with practical, install-friendly features for HVAC applications.
Product Information
Extended Description
7B34G205W81G1 ABB: General Purpose HVAC 0.75 Hp 115 V (34G205W81G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.75 AIR OVERHP,1725RPM,1PH,60HZ,56,
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
34G205W81G1
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85013100
Drive End Flange Type
Resilient Mount
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEAO
Frame Material
Steel
Frame Size
Undefined
Global Commercial Alias
34G205W81G1
Gross Volume
2110.969 in³
Gross Weight
34 lb
Insulation Class
F
Invoice Description
.75 AIR OVERHP,1725RPM,1PH,60HZ,56,3428L
Made To Order
No
Medium Description
General Purpose HVAC, .75 HP, 1800 RPM, Frame Size 56, ResilientMount Mounting, 1 Phase, 115/208-230 V, 60 Hz (34G205W81G1)
Minimum Order Quantity
1 piece
Motor Base Type
Resilient
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
N
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
0.75 Hp
Power Factor
65 %
Product Name
General Purpose HVAC
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
34 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
11.4 A | 6.3 A | 5.7 A
Rated Efficiency
66 %
Rated Speed
1725 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.63 in
Short Description
.75 HP, 1800 RPM, Frame Size 56, ResilientMount, 1 PH, 115/208-230 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
115 V | 208 V | 230 V
Feature: 0.75 HP, 1725 rpm, 1 phase, 115 V (also 208/230 V) for flexible power supply. Business Impact: Enables straightforward integration with standard HVAC controls and minimizes wiring complexity. Application: Ideal for air handlers, fans, and small ventilation units in commercial settings. Feature: TEAO enclosure and frame size 56. Business Impact: Reduces enclosure cooling requirements and enables compact installation in tight spaces. Application: Suitable for horizontal mounting on compact HVAC fans and blowers. Feature: Resilient Mount and horizontal mounting orientation. Business Impact: Dampens vibration and extends bearing life, lowering maintenance costs. Application: Direct mounting in belt-driven or direct-drive HVAC assemblies. Feature: 4-pole design with 1725 r/min rated speed and 1800 r/min synchronous speed. Business Impact: Delivers stable airflow and predictable performance across 60 Hz systems. Application: Light industrial and commercial air movement equipment with consistent duty cycles. Feature: 1-phase operation with 115 V (DC/AC options not required). Business Impact: Simplifies installation and reduces starter equipment needs, cutting total project cost. Application: Replacement in legacy HVAC systems and OEM builds requiring common single-phase power. Feature: 66% rated efficiency and 65% power factor. Business Impact: Improves energy performance and reduces electrical demand charges. Application: HVAC fans operating under continuous duty in regulated environments, supporting compliance and cost control.
