ABB 7B34J359W498 Condensor Fan - 1HP, 60Hz CSA UR
Part Number: 7B34J359W498
Quick Summary
Condensor Fan ABB 7B34J359W498 provides reliable cooling for condensers in HVAC and industrial refrigeration. This 1 HP, 115 V single-phase unit is engineered for continuous operation in demanding environments. By addressing peak load and variable condenser pressures, it helps maintain stable outlet temperatures and energy efficiency. The design carries CSA, UR, and NEMA compatibility, ensuring safe electrical interfaces and rugged construction. The compact 56C frame with C-face mounting supports straightforward installation on a wide range of equipment, while 40 °C ambient tolerance improves performance in warm rooms. For procurement, the combination of low lead times and readily available spares reduces downtime and lowers total cost of ownership.
Product Information
Extended Description
7B34J359W498 ABB: Condensor Fan 1 Hp 115 V (34J359W498)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,3450RPM,1PH,60HZ,56C,3432LC,TEN
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
34J359W498
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
C-Face
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
34J359W498
Gross Volume
20830.313 in³
Gross Weight
26 lb
Insulation Class
B
Invoice Description
1HP,3450RPM,1PH,60HZ,56C,3432LC,TENV,F1
Made To Order
No
Medium Description
Condensor Fan, 1 HP, 3600 RPM, Frame Size 56C, C-Face Mounting, 1 Phase, 115/230 V, 60 Hz (34J359W498)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
83 %
Product Name
Condensor Fan
Product Net Depth / Length
44.438 in
Product Net Height
12.5 in
Product Net Weight
26 lb
Product Net Width
37.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
9.8 A | 4.9 A
Rated Efficiency
80 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.63 in
Short Description
1 HP, 3600 RPM, Frame Size 56C, C-Face, 1 PH, 115/230 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
5 Minute
Voltage Rating
115 V | 230 V
Feature → 1 HP, 115 V single-phase operation improves condenser cooling with a compact footprint, reducing wiring complexity and energy consumption. Business Impact → Lower operating costs and easier integration with existing control systems, delivering predictable performance in commercial HVAC and light industrial condensers. Application → Ideal for air-cooled condenser units in refrigeration systems where space is at a premium and reliability is essential. Feature → 56C frame and C-Face mounting with foot-mounted base enables flexible installation and straightforward retrofit or OEM replacement. Business Impact → Faster downtime recovery and reduced modification costs, enabling seamless upgrades in equipment bays. Application → Widely compatible with a broad range of OEM condensers and wall-mounted units. Feature → Enclosure Type TE N V and 6203 ball bearings deliver robust operation in up to 40 °C ambient and challenging environments. Business Impact → Longer service life, lower maintenance intervals, and improved total cost of ownership. Application → Suitable for hot manufacturing floors and outdoor-rated condensers. Feature → Rated speed 3450 r/min with a direct-on-line starting method and 83% power factor provides strong starting torque and efficient running. Business Impact → Higher reliability during start-up, reduced current surge, and better control compatibility with standard VFDs or bypass schemes. Application → Fits standard single-phase control schemes in HVAC condensers. Feature → Rated current 9.8 A / 4.9 A and 80% rated efficiency support energy-conscious operation with predictable thermal performance. Business Impact → Lower energy bills and improved system COP, especially in multi-condenser arrays. Application → Suitable for continuous operation in commercial refrigeration and air-conditioning systems. Feature → Stocked at multiple warehouses with 0 day lead time and CSA/UR certification ensures fast, compliant procurement. Business Impact → Shorter downtime, faster maintenance cycles, and reduced safety risk. Application → Ideal for service teams requiring rapid replacement parts in North America and international facilities.
