ABB 7B34K73W312 General Purpose HVAC - TEAO Enclosure
Part Number: 7B34K73W312
Quick Summary
General Purpose HVAC motor is a compact, 0.08 HP, 110 V drive ideal for small fans and blowers. This ABB model addresses common pain points like downtime, energy waste, and installation challenges in tight spaces. It carries CE, CSA, UR certifications, plus WEEE compliance, ensuring dependable electrical safety and end-of-life compliance. With a TEAO enclosure, 1-phase operation, and a rugged 48-frame design, it delivers consistent performance in commercial HVAC and light industrial equipment. The combination of a ready-to-install footprint, stock availability at multiple warehouses, and direct-on-line starting reduces lead times and total cost of ownership, helping engineers meet uptime targets and procurement goals.
Product Information
Extended Description
7B34K73W312 ABB: General Purpose HVAC 0.08 Hp 110 V (34K73W312)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.08/KW.06HP,1400//1700RPM,1PH,50//6
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
34K73W312
Certification Agency
CE | CSA | UR | WEEE
Country of Origin
United States (US)
Customs Tariff Number
85013100
Drive End Flange Type
Standard
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEAO
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
50 Hz | 60 Hz
Global Commercial Alias
34K73W312
Gross Volume
1400.25 in³
Gross Weight
17 lb
Insulation Class
B
Invoice Description
.08/KW.06HP,1400//1700RPM,1PH,50//60HZ,4
Made To Order
No
Medium Description
General Purpose HVAC, 0.8 HP, 1200//1800 RPM, Frame Size 48, Standard Mounting, 1 Phase, TEAO Enclosure, 110//115 V, 60 Hz (34K73W31
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
48
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
N
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.08 Hp
Product Name
General Purpose HVAC
Product Net Depth / Length
13.813 in
Product Net Height
9.375 in
Product Net Weight
17 lb
Product Net Width
10.813 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.4 A | 1.2 A
Rated Speed
1400 r/min | 1700 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.5 in
Short Description
0.8 HP, 1200//1800 RPM, Frame Size 48, Standard, 1 PH, TEAO, 110//115 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1500 r/min | 1800 r/min
Type of Duty
Continuous
UNSPSC
26101105
Voltage Rating
110 V | 115 V
WEEE Category
4. Large Equipment (Any External Dimension More Than 50 cm)
Feature: TEAO enclosure and single-phase operation provide safe, maintenance-friendly operation and easy wiring. Business Impact: Reduces installation time and enclosure-related service calls, improving first-time fix rates in field applications. Application: Ideal for ceiling fans, small ventilators, and compact HVAC units in offices and retail environments. Feature: 48-frame size with foot mounting and 0.5 in shaft diameter offers flexible mounting options. Business Impact: Enables straightforward belt-drive or direct-mount configurations, lowering mounting hardware costs and space requirements. Application: Suitable for OEM fans and compact blowers where footprint is constrained. Feature: 0.08 HP, 1400/1700 rpm (50/60 Hz), 1-phase, 110/115 V ratings with DOL starting. Business Impact: Delivers predictable speed and torque with minimal drive complexity, reducing electrical noise and system wear. Application: HVAC ducting, air handling units, and small process fans. Feature: NEMA Design Code N and ball bearing 6203 support. Business Impact: Improves reliability and lifecycle performance in bearing-heavy duty cycles, lowering maintenance costs. Application: Continuous duty in ambient environments up to 40 °C. Feature: Certifications (CE, CSA, UR, WEEE) and Made in USA supply chain with stock at multiple warehouses. Business Impact: Ensures regulatory compliance, easier procurement, and shorter lead times for project schedules. Application: Industrial and commercial installations requiring standard compliance and fast delivery.
