ABB 7B34N131-0884G1 Condensor Fan, 0.33 HP - CSA/UR
Part Number: 7B34N131-0884G1
Quick Summary
ABB 7B34N131-0884G1 Condensor Fan is a compact, reliable cooling solution for condenser duties in HVAC systems and industrial chillers. It delivers 0.33 HP at 1725 rpm and runs on a 3-phase, 60 Hz supply with a versatile 230/460 V rating. This Baldor-Reliance unit is built around a 48Z frame and TEFC enclosure for robust protection in demanding environments. For engineers facing downtime and supply-chain constraints, the model offers immediate stock across multiple warehouses and a straightforward Direct On Line start that simplifies installation. With NEMA design code B and a 6203 ball bearing, it supports long life in continuous operation, delivering predictable cooling and total-cost-of-ownership benefits. The product also aligns with US-origin sourcing and CSA/UR certifications for compliance and reliability.
Product Information
Extended Description
7B34N131-0884G1 ABB: Condensor Fan 0.33 Hp 230 V (34N131-0884G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.33HP,1725RPM,3PH,60HZ,48Z,3413M,TE
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
34N131-0884G1
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Drive End Flange Type
Standard
Efficiency Level
Not Regulated / Exempt | Undefined Efficiency
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
34N131-0884G1
Gross Volume
2110.969 inÂł
Gross Weight
21 lb
Insulation Class
B
Invoice Description
.33HP,1725RPM,3PH,60HZ,48Z,3413M,TEFC,F1
Made To Order
No
Medium Description
Condensor Fan, 0.33 HP, 1800 RPM, Frame Size 48Z, Standard Mounting, 3 Phase, 230/460 V, 60 Hz (34N131-0884G1)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
48Z
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
0.33 Hp
Power Factor
57 %
Product Name
Condensor Fan
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
21 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.6 A | 0.8 A
Rated Efficiency
68 %
Rated Speed
1725 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.5 in
Short Description
0.33 HP, 1800 RPM, Frame Size 48Z, Standard, 3 PH, 230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Feature: TEFC enclosure and 48Z frame provide robust protection against dust and moisture while enabling straightforward mounting in tight mechanical spaces. Business Impact: Increased uptime and reduced field maintenance, especially in outdoor condenser applications, with predictable airflow. Application: Ideal for outdoor HVAC condensers and industrial cooling units where protection and ease of service matter.Feature: 0.33 HP, 1725 rpm, 60 Hz performance delivers targeted airflow with compact footprint. Business Impact: Improved condenser heat rejection and energy efficiency, contributing to lower runtime costs and steadier process temperatures. Application: Suitable for standard 3-phase condenser tasks in offices, data centers, and process cooling plants.Feature: Direct on Line starting and 3-phase operation. Business Impact: Simplified electrical wiring and faster commissioning, reducing installation time and wiring costs. Application: OEM integrations and retrofit projects where quick startup is essential.Feature: 230/460 V dual-voltage support and 3-phase supply. Business Impact: Flexibility across global facilities, reducing the need for multiple SKUs and simplifying procurement. Application: International deployments and multi-site manufacturing environments.Feature: NEMA B design, ball bearing 6203, and foot-mounted horizontal orientation. Business Impact: Improved reliability under continuous duty with long bearing life and stable performance. Application: Continuous condenser cooling in harsh industrial settings and service-intensive installations.Feature: Stock availability and US origin with CSA/UR certification. Business Impact: Shorter lead times, regulatory confidence, and easier vendor qualification. Application: OEM sourcing and maintenance operations seeking compliant, ready-to-ship components.
