ABB 7B35M644T321 General Purpose Motor - NEMA
Part Number: 7B35M644T321
Quick Summary
General purpose motor 7B35M644T321 delivers reliable 2 HP single‑phase drive for light industrial equipment and OEM lines. This compact open‑frame offering is engineered for versatile installation in horizontal, foot‑mounted configurations, supporting 50/60 Hz operation at 220/230 V. When selecting a motor for mixed regional warehouses, this model helps simplify procurement with fast stock and consistent performance across multiple sites. You gain predictable torque, straightforward direct-on-line starting, and a footprint compatible with standard Baldor‑Reliance form factors (frame 56). The ABB design also emphasizes safety and compliance, aligning with NEMA and CSA/UR certifications. For integrators, the combination reduces installation risk and accelerates time‑to‑operation while delivering ongoing cost efficiency.
Product Information
Extended Description
7B35M644T321 ABB: General Purpose Motor 2 Hp 220 V (35M644T321)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,2850//3450RPM,1PH,50//60HZ,56,3
Ambient Temperature
50 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
35M644T321
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
50 Hz | 60 Hz
Global Commercial Alias
35M644T321
Gross Volume
2110.969 in³
Gross Weight
50 lb
Insulation Class
F
Invoice Description
2HP,2850//3450RPM,1PH,50//60HZ,56,3535C
Made To Order
No
Medium Description
General Purpose 1PH Open, 2 HP, 3000//3600 RPM, Frame Size 56, Standard Mounting, 1 Phase, 220//230 V, 60 Hz (35M644T321)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp
Product Name
General Purpose 1PH Open
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
50 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
9.1 A | 8.5 A
Rated Speed
2850 r/min | 3450 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.63 in
Short Description
2 HP, 3000//3600 RPM, Frame Size 56, Standard, 1 PH, 220//230 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3000 r/min | 3600 r/min
Type of Duty
Continuous
Voltage Rating
220 V | 230 V
2 HP, 1PH motor operates at 220/230 V with 50/60 Hz, offering reliable torque for conveyors, pumps, and small machinery. Business impact: simple electrical design and broad compatibility reduce engineering time and startup risk, accelerating time to first run in OEM lines. Application: ideal for belt conveyors, fans, and liquid pumps in light industrial setups with open frame, frame size 56, and foot mounting for quick installation.2 HP, 1PH, 220/230 V operation with 50/60 Hz support enables global procurement and consistent performance across regional facilities, reducing inventory fragmentation. Business impact: standardized Baldor‑Reliance components simplify spare parts management and maintenance planning. Application: seamless integration with existing Baldor catalog parts, easing retrofits and new equipment builds.1PH, 2P, 2850/3450 rpm speeds offer flexible speed selection for varying loads, while a direct on line starting method minimizes control complexity and energy spikes. Business impact: improved startup reliability and reduced downtime in continuous duty applications. Application: suitable for compact packaging lines, small mixers, and control panels across manufacturing environments.1.15 service factor and insulation class F deliver durable operation under typical industrial ambient conditions up to 50 °C. Business impact: extended motor life, lower maintenance costs, and predictable performance in demanding environments. Application: critical for repetitive duty cycles and high‑throughput equipment. Certifications to NEMA standards plus CSA | UR markings provide compliance confidence for regulated industries. Application: suitable for regulated OEM projects and global installations with strict safety requirements. Stock availability across multiple warehouses minimizes lead times, enabling faster project timelines. Business impact: faster commissioning and reduced capital lock‑in. Application: essential for short‑cycle production lines and urgent retrofit projects.
