ABB 7B35N830L366G1 Motor - IE3 Efficiency, 380V 50Hz
Part Number: 7B35N830L366G1
Quick Summary
ABB 7B35N830L366G1 Motor is a robust U-frame drive for continuous industrial applications. Engineers often struggle to balance energy efficiency, installation ease, and supplier reliability in motor purchases. This model delivers IE3 efficiency alongside CSA EEV, NEMA Premium, and UR listed certifications, helping you meet regulatory requirements while reducing total cost of ownership. Designed for 380 V, 50 Hz, 3-phase systems, it ships in stock across multiple warehouses and supports quick deployment in OEM equipment and plant upgrades. With a compact 184 frame, foot mounting, and straightforward direct-on-line starting, it fits a wide range of pumps, fans, and conveyors while offering dependable performance for continuous operation.
Product Information
Extended Description
7B35N830L366G1 ABB: U-Frame 3 Hp 380 V (35N830L366G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
3HP,2850RPM,3PH,50HZ,184,3534M,OPSB
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
35N830L366G1
Certification Agency
CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
IE3
Electrical Data
Enclosure Type
OPSB
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
50 Hz
Global Commercial Alias
35N830L366G1
Gross Volume
3496.049 in³
Gross Weight
56 lb
Insulation Class
F
Invoice Description
3HP,2850RPM,3PH,50HZ,184,3534M,OPSB,F1,N
Made To Order
No
Medium Description
U-Frame, 3 HP, 3000 RPM, Frame Size 184, Standard Mounting, 3 Phase, 380 V, 50 Hz (35N830L366G1)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
3 Hp
Power Factor
89 %
Product Name
U-Frame
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
56 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.4 A
Rated Efficiency
86.50 %
Rated Speed
2850 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
0.88 in
Short Description
3 HP, 3000 RPM, Frame Size 184, Standard, 3 PH, 380 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3000 r/min
Type of Duty
Continuous
Voltage Rating
380 V
Feature: IE3 efficiency rating. Business Impact: Reduces energy consumption and operating costs over the motor’s life. Application: Ideal for pumps, fans, and conveyors in manufacturing zones seeking lower energy bills and improved sustainability. Feature: Direct-on-Line starting. Business Impact: Simplifies commissioning and minimizes control hardware, reducing installation time and maintenance. Application: Common in line-start scenarios where fast, reliable startup is required. Feature: 184 frame, 3 HP, 2P, 2850 rpm. Business Impact: Compact footprint with robust performance, enabling easy retrofit into existing equipment. Application: OEM drives, packaging lines, and material handling systems. Feature: Enclosure Type OPSB and Foot Mounted mounting. Business Impact: Easier installation, protection in harsh environments, and flexibility for horizontal layouts. Application: End-user machines and packaging equipment requiring reliable mounting. Feature: Certifications and stock availability (CSA EEV, NEMA Premium, UR; 0 day lead time; multiple warehouses). Business Impact: Compliance assurance and shorter time-to-production, improving ROI. Application: Global procurement for plant-wide upgrades and new builds.
