ABB 7B35P024W532H2 General Purpose Motor - TEFC
Part Number: 7B35P024W532H2
Quick Summary
ABB 7B35P024W532H2 is a general purpose, 0.33 HP motor for 3-phase drives in light industrial equipment. This compact, robust unit is designed for reliable operation in conveyors, fans, and pumps, delivering consistent performance at 60 Hz. Engineers often struggle with compatibility, mounting challenges, and downtime from mismatched motors; this model addresses those issues with a TEFC enclosure and a 56C frame that fits standard drive systems. It carries CSA and UR certifications along with alignment to NEMA standards, ensuring safe, regulatory-compliant installation. With US-origin stock and 0-day lead times, this motor supports fast procurement and reduced project delays, while its energy profile and simple integration deliver tangible business value.
Product Information
Extended Description
7B35P024W532H2 ABB: General Purpose Motor 0.33 Hp 208 V (35P024W532H2)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.33HP,1625RPM,3PH,60HZ,56C,3512M,TE
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
35P024W532H2
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Drive End Flange Type
C-Face
Efficiency Level
Not Regulated / Exempt | Undefined Efficiency
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
35P024W532H2
Gross Volume
2110.969 in³
Gross Weight
29 lb
Insulation Class
H
Invoice Description
.33HP,1625RPM,3PH,60HZ,56C,3512M,TEFC,F1
Made To Order
No
Medium Description
General Purpose 3PH Enclosed, 0.33 HP, 1800 RPM, Frame Size 56C, C-Face Mounting, 3 Phase, 208-230/460 V, 60 Hz (35P024W532H2)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56C
Mounting Orientation
Horizontal
Mounting Position
F1
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
0.33 Hp
Power Factor
56 %
Product Name
General Purpose 3PH Enclosed
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
29 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
1.4 A | 1.3 A | 0.65 A
Rated Efficiency
68 %
Rated Speed
1625 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.63 in
Short Description
0.33 HP, 1800 RPM, Frame Size 56C, C-Face, 3 PH, 208-230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
208 V | 230 V | 460 V
Feature → Business Impact → Application: The 0.33 HP output at 1625 RPM delivers compact, efficient power for small conveyors, fans, and pumps, reducing space requirements and energy use while maintaining reliable torque for light-duty tasks. This translates to lower lifecycle costs and better line utilization in material handling and processing lines. Feature → Business Impact → Application: TEFC enclosure and 56C frame provide rugged enclosure and standardized mounting compatibility, enabling straightforward installation on existing skids and equipment, minimizing retrofit risks and downtime in manufacturing environments. Feature → Business Impact → Application: Direct-on-line start capability and absence of a braking system simplify motor control, cut upfront drive costs, and improve startup reliability in batch processing or packaging lines. Feature → Business Impact → Application: Broad voltage tolerance (208/230/460 V) and 60 Hz operation support multiple regional power networks, reducing wiring changes and spare parts; ideal for globally deployed machinery and mixed-plant implementations. Feature → Business Impact → Application: High-quality bearings and insulation class (H) enhance durability in continuous duty applications, lowering maintenance frequency and extending service life for conveyors and pump assemblies. Feature → Business Impact → Application: Stock availability across multiple warehouses and a flat 0-day lead time minimize downtime and accelerate project timelines, particularly in OEM integrations and turnkey automation projects.
