ABB 7B35T696T403G1 General Purpose Motor - NEMA Premium IE3
Part Number: 7B35T696T403G1
Quick Summary
ABB 7B35T696T403G1 is a general purpose 1 HP three-phase motor for industrial drives such as conveyors and pumps. In real-world plants, downtime and mismatched supply can derail production and inflate operating costs. The motor carries NEMA design B with IE3 (NEMA Premium) efficiency, plus CSA EEV and UR recognitions, supporting safety, energy compliance, and regulatory readiness across North America and beyond. With 0-day lead time and broad warehouse stock, it enables rapid replacements and predictable maintenance budgeting, while TEFC enclosure, 56-frame size, and foot mounting simplify installation into standard OEM line equipment.
Product Information
Extended Description
7B35T696T403G1 ABB: General Purpose Motor 1 Hp 200 V (35T696T403G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
1HP,3450RPM,3PH,60HZ,56,3516M,TEFC,
Ambient Temperature
40 °C
Bearing
6205, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
35T696T403G1
Certification Agency
CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015100
Drive End Flange Type
Standard
Efficiency Level
2015 Small Motor Standard | IE3 | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
35T696T403G1
Gross Volume
2110.969 in³
Gross Weight
33 lb
Insulation Class
F
Invoice Description
1HP,3450RPM,3PH,60HZ,56,3516M,TEFC,F1,N
Made To Order
No
Medium Description
General Purpose 3PH Enclosed, 1 HP, 3600 RPM, Frame Size 56, Standard Mounting, 3 Phase, TEFC Enclosure, 200 V, 60 Hz (35T696T403G1)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
1 Hp
Power Factor
82 %
Product Name
General Purpose 3PH Enclosed
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
33 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
3.2 A
Rated Efficiency
84 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.25
Shaft Diameter
0.63 in
Short Description
1 HP, 3600 RPM, Frame Size 56, Standard, 3 PH, TEFC, 200 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101112
Voltage Rating
200 V
TEFC enclosure and 56-frame design deliver rugged protection against dust and moisture, extending motor life in harsh factory environments. This directly reduces unscheduled downtime and maintenance costs for conveyors and pumps in manufacturing lines. The IE3 (NEMA Premium) efficiency and insulation class F deliver energy savings and stable performance under load, lowering operating costs and improving power factor in continuous duty applications such as pumps and fans. Two-pole, 3450 r/min operation at 60 Hz and 200 V with direct-on-line starting supports fast, reliable starts, minimizing startup surge and improving throughput in OEM equipment like conveyors and packaging lines. Foot-mounted, horizontal F1 mounting with a 56 frame and a compact 16.5 in length simplifies retrofit, OEM integration, and service access, reducing installation time and enclosure footprint. 0-day lead time with multi-warehouse stock enables rapid replacements and predictable procurement budgeting, while certifications such as NEMA design, CSA EEV, and UR recognition aid regulatory compliance and customer audits. The service factor of 1.25 provides headroom for peak loads, reducing the risk of overheating during transient operating conditions and extending motor life in demanding applications.
