ABB 7B35U647-0506G2 General Purpose Motor - CSA/UR
Part Number: 7B35U647-0506G2
Quick Summary
ABB 7B35U647-0506G2 General Purpose Motor is a 2 HP, single-phase drive designed for conveyors, fans, and pumps in industrial settings. This model addresses common sizing and mounting challenges with a compact footprint and a robust TEFC enclosure that simplifies installation and reduces downtime. It carries CSA and UR certifications and is aligned with NEMA standards, providing regulatory confidence for North American facilities. With a 145TCYZ frame, 1 phase, 115/230 V, and 60 Hz operation, it supports quick wiring, straightforward commissioning, and reliable service life for continuous duty applications.
Product Information
Extended Description
7B35U647-0506G2 ABB: General Purpose Motor 2 Hp 115 V (35U647-0506G2)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2HP,3450RPM,1PH,60HZ,145TCYZ,3535L,
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
35U647-0506G2
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Non-Standard
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
35U647-0506G2
Gross Volume
5274.135 in³
Gross Weight
54 lb
Insulation Class
F
Invoice Description
2HP,3450RPM,1PH,60HZ,145TCYZ,3535L,TEFC
Made To Order
No
Medium Description
General Purpose 1PH Enclosed, 2 HP, 3600 RPM, Frame Size 145Tcyz, NonStandard Mounting, 1 Phase, 115/230 V, 60 Hz (35U647-0506G2)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
145TCYZ
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
L
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp
Power Factor
82 %
Product Name
General Purpose 1PH Enclosed
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
54 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
23 A | 11.5 A
Rated Efficiency
74 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.25
Shaft Diameter
0.5 in
Short Description
2 HP, 3600 RPM, Frame Size 145Tcyz, NonStandard, 1 PH, 115/230 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
Voltage Rating
115 V | 230 V
Feature → Business Impact → Application: The TEFC enclosure paired with a 145TCYZ frame offers enhanced protection against dust and moisture, reducing fault risk and enabling dense panel layouts in packaging lines and process equipment. This translates to lower maintenance costs and longer mean time between failures for conveyors, fans, and small pumps. Feature → Business Impact → Application: The 1-phase, dual-voltage 115/230 V rating simplifies electrical sourcing and installation, cutting wiring complexity and spare parts stock, which is especially valuable in retrofit projects for HVAC, light industrial machinery, and batching systems. Feature → Business Impact → Application: Direct-on-line starting reduces startup time and hardware needs, accelerating commissioning and minimizing startup torque requirements on light-duty loads such as material handling and cooling fans. Feature → Business Impact → Application: Foot-mounted horizontal mounting and a standard 145TCYZ frame streamline retrofits by matching common baselines, enabling faster alignment and repeatable performance in conveyors, pumps, and general-purpose equipment. Feature → Business Impact → Application: With a 74% rated efficiency and a 23 A / 11.5 A current profile, operating costs are kept predictable while energy-conscious facilities optimize utility spend on continuous-duty tasks like cooling, ventilation, and small process drives. Feature → Business Impact → Application: CSA/UR certifications and NEMA-aligned design deliver regulatory compliance, helping procurement teams meet quality standards and reduce certification risk during audits and vendor qualification.
Get a Quick Quote for a ABB 7B35U647-0506G2
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7B35U647-0506G2?
Enquire Now
FAQs
This motor is designed for dual-voltage operation (115 V or 230 V) on a single phase, simplifying wiring and panel design. It supports direct connection to common 1PH power sources without special transformers, reducing install time and minimizing potential voltage mismatch. For retrofit projects, verify supply voltage matches the motor nameplate and ensure current at the chosen voltage remains within 11.5 A (230 V) or 23 A (115 V) ratings.
Key specs include a 145TCYZ frame, TEFC enclosure, horizontal foot-mounted orientation, and a 2 HP rating at 3450 rpm (single-speed). Shaft diameter is 0.5 in, with a rated current of 23 A at 115 V or 11.5 A at 230 V. The unit is intended for continuous-duty operation with a 60 Hz supply and NEMA design L characteristics.
Yes. The 2 HP, 1PH, 60 Hz ABB motor is well-suited for conveyors, fans, and small pumps in retrofit environments. Its footprint, foot-mounted mounting, and 145TCYZ frame align with common legacy installations. Direct-on-line starting and compact enclosure help minimize footprint while maintaining performance, making it a practical drop-in replacement in many light-to-moderate load duty cycles.
The motor carries CSA and UR certification designations and aligns with NEMA standards, supporting compliance in North American facilities. This combination reduces auditors’ questions during vendor qualification and supplier audits, streamlines procurement, and helps ensure regulatory conformance for safety and performance requirements in manufacturing and packaging lines.
Expect low maintenance due to a robust TEFC enclosure and simple direct-start electrical design, contributing to shorter downtime and higher uptime. ROI is driven by energy efficiency (74% rated efficiency), reduced wiring complexity, and longer service life in continuous-duty applications such as cooling, ventilation, and light industrial automation. Plan for routine bearing checks and inspection of the 0.5 in shaft and mounting hardware.
