ABB 7B36G510X288G1 General Purpose Motor - CSA UR
Part Number: 7B36G510X288G1
Quick Summary
ABB 7B36G510X288G1 General Purpose Motor delivers 6 HP at 230 V for open-frame, single-phase drive systems. This compact, reliable motor is designed to minimize downtime in pumps, fans, and conveyors by offering a standard 184T frame, 1-phase, 60 Hz input, and direct-on-line starting. For engineers facing integration challenges, the model aligns with common industry frames and mounting practices, ensuring quick replacement without custom fitting. With CSA | UR certification and adherence to NEMA-based guidelines, this motor provides predictable compliance for U.S. and international projects. The combination of strong electrical performance and practical enclosure options supports scalable applications while keeping total cost of ownership low in production environments.
Product Information
Extended Description
7B36G510X288G1 ABB: General Purpose Motor 6 Hp 230 V (36G510X288G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
6HP,1725RPM,1PH,60HZ,184T,3646LC,OD
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
36G510X288G1
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
ODTF
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
36G510X288G1
Gross Volume
5274.135 in³
Gross Weight
96 lb
Insulation Class
F
Invoice Description
6HP,1725RPM,1PH,60HZ,184T,3646LC,ODTF,F1
Made To Order
No
Medium Description
General Purpose 1PH Open, 6 HP, 1800 RPM, Frame Size 184T, Standard Mounting, 1 Phase, 230 V, 60 Hz (36G510X288G1)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
L
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
6 Hp
Power Factor
90 %
Product Name
General Purpose 1PH Open
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
96 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
26 A
Rated Efficiency
83 %
Rated Speed
1725 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.13 in
Short Description
6 HP, 1800 RPM, Frame Size 184T, Standard, 1 PH, 230 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V
Feature → Business Impact → Application: Electrical specifications of 230 V, 1-phase, 60 Hz input deliver consistent start-up torque and stable speed, reducing energy waste and enhancing process control in light-industrial equipment like pumps and fans. This translates to measurable efficiency gains and lower maintenance costs in daily operation. Feature → 6 HP output with 1725 r/min nominal speed improves load handling for conveyors and small machinery, enabling reliable throughput without oversizing drives. Application: suitable for compact open-frame drives in material handling and HVAC applications. Feature → Enclosure Type ODtf and Frame Size 184T offer durable enclosure and compatible footprint for horizontal, foot-mounted installation, simplifying retrofits and new builds. Application: open-frame general purpose motors in assembly lines and process cooling systems. Feature → Bearing arrangement (6206 ball, 6205 NDE) and Insulation Class F provide long service life and resistance to typical factory temperatures, reducing unplanned downtime and extending maintenance cycles. Application: high-cycle conveyors and pumps with frequent starts. Feature → Rated Current 26 A and Power Factor 90% support precise electrical design and safe electrical sharing in panel layouts, enabling engineers to optimize protection and energy costs. Application: electrical distribution planning for small-industrial plants. Feature → Direct-on-Line starting and 1PH operation simplify installation and commissioning, cutting commissioning time and accelerating time-to-production. Application: quick replacements and rapid line start in packaging, water treatment, and light manufacturing. Industry context: these characteristics align with long-standing Baldor-Reliance standards, supporting compatibility with existing motor bases, couplings, and drive systems while delivering predictable ROI through reduced downtime and streamlined maintenance.
Get a Quick Quote for a ABB 7B36G510X288G1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7B36G510X288G1?
Enquire Now
FAQs
This motor is rated for 230 V, 1-phase, 60 Hz operation and uses a standard 184T frame with 1.13 in shaft, making it compatible with common open-frame mounting patterns and existing electrical cabinets. Direct-on-line starting reduces additional starter equipment, while the foot-mounted orientation simplifies retrofit into most light-industrial setups.
Key specs include 6 HP output, 1725 r/min (nominal), 60 Hz, 230 V, and 26 A rated current with a 90% power factor. Insulation class is F, enclosure is ODTF, and the motor uses 6206 ball bearings with 6205 NDE. These figures translate to predictable torque, efficient operation, and durable performance in continuous service.
Yes. The motor is rated for continuous duty and features a robust enclosure (ODTF) and a frame size (184T) that supports reliable cooling and mounting in open environments. Direct-on-line starting and 1PH operation further simplify integration in steady-state production lines.
The product carries CSA | UR certification, aligning with electrical safety requirements for the U.S. and Canada. It also adheres to NEMA-based design practices, with a standard 184T frame and 1PH 60 Hz operation, which helps in meeting regional installation codes and procurement standards.
Maintenance benefits come from a simple, robust ball-bearing arrangement, a standard shaft, and an insulation class F that tolerates typical plant temperatures. With a footprint compatible with common bases and minimal control hardware due to DOL starting, downtime is reduced and total cost of ownership improves through longer service intervals and faster replacements.
