ABB 7B36H970W849G1 General Purpose Motor - 1PH 60Hz CSA/UR
Part Number: 7B36H970W849G1
Quick Summary
General Purpose Motor 5 HP 230 V is designed for reliable, single-phase industrial drives across conveyors, pumps, and fans. This ABB unit delivers robust open-enclosure performance with a 184T frame and 1725 RPM to balance torque and efficiency in demanding environments. If you’re battling downtime due to undersized drives, this model offers ample startup current and steady operation under 60 Hz loads. It carries CSA and UR certifications, and aligns with NEMA standards for broad compatibility with legacy equipment. With stock available across multiple warehouses, you can reduce lead times and simplify procurement, while still meeting project budgets and safety requirements through a proven, maintenance-friendly design.
Product Information
Extended Description
7B36H970W849G1 ABB: General Purpose Motor 5 Hp 230 V (36H970W849G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1725RPM,1PH,60HZ,184T,3640LC,OP
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
36H970W849G1
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
OPEN
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
36H970W849G1
Gross Volume
3590.443 in³
Gross Weight
91 lb
Insulation Class
F
Invoice Description
5HP,1725RPM,1PH,60HZ,184T,3640LC,OPEN,F3
Made To Order
No
Medium Description
General Purpose 1PH Open, 5 HP, 1800 RPM, Frame Size 184T, Standard Mounting, 1 Phase, 230 V, 60 Hz (36H970W849G1)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184T
Mounting Orientation
Horizontal
Mounting Position
F3
NEMA Design Code
L
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
87 %
Product Name
General Purpose 1PH Open
Product Net Depth / Length
22.875 in
Product Net Height
12.813 in
Product Net Weight
91 lb
Product Net Width
12.25 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
23 A
Rated Efficiency
82.50 %
Rated Speed
1725 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.13 in
Short Description
5 HP, 1800 RPM, Frame Size 184T, Standard, 1 PH, 230 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
230 V
Feature → Business Impact → Application. The 5 HP, 230 V, 1PH configuration delivers sufficient torque for light to moderate open-drive duties, reducing cycle times and improving process reliability in material handling and pumping applications. This translates to lower energy waste and better uptime in manufacturing lines. The 184T frame size with a 1.13 in shaft diameter supports straightforward mounting and alignment, minimizing retrofit risks when replacing legacy motors. The open enclosure design enables easy cooling and service access, accelerating maintenance and reducing downtime during routine checks. With a 1725 r/min rated speed and 60 Hz operation, the motor provides predictable performance for conveyors and fans under typical load profiles, aided by a 0.87 power factor and 82.5% efficiency for energy-conscious operation. Compatibility with Baldor-Reliance branding ensures broad spare parts availability and long-term support, while direct-on-line starting simplifies electrical integration and start-up sequencing for quick installation. In demanding environments, the 1P configuration and NEMA-aligned standards help meet compliance requirements and simplify procurement across multiple facilities.
