ABB 7B36J109X868H2 HVAC Motor - IE2, CSA/UR Certified
Part Number: 7B36J109X868H2
Quick Summary
General Purpose HVAC Motor ABB 7B36J109X868H2 delivers reliable 2 HP performance for commercial HVAC fans and pumps. Many facilities struggle with startup surges, thermal buildup, and energy waste; this 3-phase TEAO motor minimizes inrush and heat while operating across a broad voltage range (190–460 V). Certified to CSA and UR safety standards and rated IE2 for energy efficiency, it meets common industrial compliance needs and reduces operating costs. With a rugged 184TCZ frame, C-face mounting, and 60 Hz compatibility, installation is straightforward in existing equipment. Stocked at multiple warehouses, it supports fast procurement and predictable lead times, enabling faster project ramp-up and reliable uptime.
Product Information
Extended Description
7B36J109X868H2 ABB: General Purpose HVAC 2 Hp 190 V (36J109X868H2)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2//1.5 AIR OVERHP,1160//960RPM,3PH,
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
36J109X868H2
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
C-Face
Efficiency Level
IE2 | Energy Efficiency (NEMA 12-11) | Not Regulated / Exempt
Electrical Data
Enclosure Type
TEAO
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
50 Hz | 60 Hz
Global Commercial Alias
36J109X868H2
Gross Volume
3590.443 in³
Gross Weight
75 lb
Insulation Class
B
Invoice Description
2//1.5 AIR OVERHP,1160//960RPM,3PH,60//5
Made To Order
No
Medium Description
General Purpose HVAC, 2//1.5 HP, 1200//1000 RPM, Frame Size 184Tcz, C-Face Mounting, 3 Phase, 208-230/460//190/380 V, 60 Hz (36J109X
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184TCZ
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
6P
Number of Poles (High)
6
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2 Hp | 1.50 Hp
Power Factor
63 %
Product Name
General Purpose HVAC
Product Net Depth / Length
22.875 in
Product Net Height
12.813 in
Product Net Weight
75 lb
Product Net Width
12.25 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
6.4 A | 3.2 A | 7.6 A | 7 A | 3.5 A
Rated Efficiency
86.50 %
Rated Speed
1160 r/min | 960 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.13 in
Short Description
2//1.5 HP, 1200//1000 RPM, Frame Size 184Tcz, C-Face, 3 PH, 208-230/460//190/380 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1000 r/min | 1200 r/min
Type of Duty
Continuous
Voltage Rating
190 V | 208 V | 230 V | 380 V | 460 V
Feature: 3-phase TEAO enclosure with 2 HP rating and broad voltage range (190–460 V). Business Impact: Simplifies procurement and wiring, enabling plug-and-play integration in diverse HVAC installations. Application: Commercial buildings with variable power availability. Feature: IE2 efficiency (≈86.5%). Business Impact: Reduces energy consumption and lifecycle costs in continuous operation environments. Application: Air handlers and supply fans in high-usage buildings. Feature: 184TCZ frame, 6-pole design, 1160/960 r/min. Business Impact: Predictable torque and speed for stable HVAC airflow, improving control and comfort. Application: Industrial fans and belt-drive HVAC units. Feature: TEAO enclosure with Direct on Line start capability. Business Impact: Faster setup and lower maintenance, reducing downtime during commissioning. Application: New installations and retrofits without enclosure cooling complications. Feature: Foot-mounted with C-face flange compatibility. Business Impact: Easy retrofits and straightforward mounting in existing equipment footprints. Application: Replacements in packaged HVAC motors and fan assemblies. Feature: 3-phase, 60 Hz operation with multiple voltage options (190/208–230/380/460 V). Business Impact: Flexible installation across regional power grids, lowering spare parts inventory. Application: Global projects and multi-site facilities.
