ABB 36J364S268G1 Hydraulic Pump - 5HP, IE3 Premium Efficiency
Part Number: 7B36J364S268G1
Quick Summary
Hydraulic Pump ABB 36J364S268G1 delivers a reliable 5 HP, three‑phase drive for industrial hydraulic systems used in presses, conveyors, and molding equipment. This unit is engineered for US procurement with a 208-230/460 V, 60 Hz supply and a TEFC enclosure, simplifying installation and reducing field modifications. The design emphasizes premium efficiency, durable steel frame, and a compact 184YZ footprint to fit tight spaces while meeting fast changeover needs. With certifications CSA EEV, UR, and NEMA Premium, it helps you address regulatory and energy compliance with confidence. Stocked at multiple warehouses and supported by a zero-day lead time, this pump enables rapid deployment, predictable maintenance, and lower total cost of ownership in demanding manufacturing environments.
Product Information
Extended Description
7B36J364S268G1 ABB: Hydraulic Pump 5 Hp 208 V (36J364S268G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,1750RPM,3PH,60HZ,184YZ,3642M,TE
Ambient Temperature
40 °C
Bearing
6208, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
36J364S268G1
Certification Agency
CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
SAE Pump
Efficiency Level
IE3 | Not Regulated / Exempt | Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
36J364S268G1
Gross Volume
5274.135 in³
Gross Weight
93 lb
Insulation Class
H
Invoice Description
5HP,1750RPM,3PH,60HZ,184YZ,3642M,TEFC,F1
Made To Order
No
Medium Description
Hydraulic Pump, 5 HP, 1800 RPM, Frame Size 184YZ, SaePump Mounting, 3 Phase, 208-230/460 V, 60 Hz (36J364S268G1)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184YZ
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
78 %
Product Name
Hydraulic Pump
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
93 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
13.9 A | 13.4 A | 6.7 A
Rated Efficiency
89.50 %
Rated Speed
1750 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Shaft Diameter
1.56 in
Short Description
5 HP, 1800 RPM, Frame Size 184YZ, SaePump, 3 PH, 208-230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
208 V | 230 V | 460 V
Feature: 5 HP output with rated speed of 1750 r/min delivers sufficient hydraulic power for continuous operation in presses, molding lines, and material handling. Business Impact: Enables shorter cycle times and consistent actuation, lowering overall production costs. Application: Ideal for high-demand stamping and forming applications that require dependable, on-spec torque. Long-tail keyword focus: 5 HP hydraulic pump, 3-phase hydraulic motor, continuous duty pump.Feature: Voltage rating of 208-230/460 V, 60 Hz, and 3-phase input provides flexible electrical sourcing and easy integration with existing plant power systems. Business Impact: Simplifies procurement and reduces wiring changes during retrofit projects. Application: Suitable for US-based facilities upgrading legacy equipment to modern electric drives. Long-tail keyword focus: 208-230/460V hydraulic drive, 3-phase 60 Hz motor, versatile cooling and control.Feature: TEFC enclosure, frame size 184YZ, and foot-mounted orientation improve durability and installation simplicity. Business Impact: Enhances protection in dirty environments and enables straightforward mounting with predictable alignment. Application: Suitable for compact footprints in presses and conveyors where floor mounting is required. Long-tail keyword focus: TEFC hydraulic motor, 184YZ frame, foot mounted pump.Feature: IE3 Premium Efficiency rating and service factor 1.15 reduce energy use and extend motor life. Business Impact: Delivers energy savings and improved lifecycle costs in continuous operation. Application: Industrial hydraulics that demand energy-efficient performance across multiple shifts. Long-tail keyword focus: IE3 efficiency motor, premium efficiency hydraulic pump, energy savings.Feature: Direct on line starting and 4‑pole design support reliable startup and stable operation. Business Impact: Minimizes required soft-starter hardware and reduces maintenance complexity. Application: Small to mid-scale hydraulic systems in tooling and automation lines. Long-tail keyword focus: Direct on line start, 4-pole motor, reliable startup.Feature: Stocked At Warehouses (US and international) with zero-day lead time capability. Business Impact: Accelerates procurement and reduces downtime risk during plant modernization. Application: Quick replacement in critical lines and fast deployment in new projects. Long-tail keyword focus: in-stock hydraulic pumps, quick delivery, US stock.
Get a Quick Quote for a ABB 7B36J364S268G1
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7B36J364S268G1?
Enquire Now
FAQs
This pump expects a 3‑phase 208‑230/460 V supply at 60 Hz. It is designed for direct‑on‑line starting and mounting in a foot‑mounted configuration with a TEFC enclosure, simplifying wiring during retrofit or new installation and reducing the need for external soft starters in many applications.
Key specs include 5 HP output with a rated speed of 1750 r/min and a synchronous speed of 1800 r/min. The shaft diameter is 1.56 in, and the service factor is 1.15. It operates at IE3 premium efficiency and uses durable 6208 ball bearings for long life in continuous service.
Yes. The 5 HP, 3‑phase design with frame 184YZ and TEFC enclosure is well matched to hydraulic actuation in presses and conveyors, offering reliable startup, consistent torque, and energy efficiency suitable for continuous operation across shift work.
The pump carries CSA EEV, NEMA Premium, and UR certifications. These confirm energy efficiency, electrical safety, and regulatory compliance, helping you meet industry standards and customer requirements while reducing risk in procurement and installation.
Warranty notes indicate a warranty return policy with the product to be returned if under warranty. The unit is stocked at multiple warehouses to support fast replacement and predictable maintenance, with a minimum order of 1 piece and 0 day lead time in some locations.
