ABB 36Q745N013G1 Hydraulic Pump - Premium Efficiency
Part Number: 7B36Q745N013G1
Quick Summary
Hydraulic Pump from ABB delivers 2.2 kW of hydraulic power for 3-phase, 460 V actuation in industrial equipment. If space is tight or uptime is critical, you need a unit that combines compact footprint with dependable performance. This model is certified for CSA EEV and UR recognition, with a NEMA-compliant TEFC enclosure and Premium Efficiency ratings, supporting safe operation in demanding environments. Built to integrate with frame D100Z and SaePump mounting, it aligns with 60 Hz systems while delivering robust power and predictable maintenance needs for manufacturing and process automation.
Product Information
Extended Description
7B36Q745N013G1 ABB: Hydraulic Pump 2.20 kW 460 V (36Q745N013G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
2.2KW,1755RPM,3PH,60HZ,D100Z,3632M,
Ambient Temperature
40 °C
Bearing
6208, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
36Q745N013G1
Certification Agency
CSA EEV | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
SAE Pump
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
36Q745N013G1
Gross Volume
3496.049 in³
Gross Weight
73 lb
Insulation Class
F
Invoice Description
2.2KW,1755RPM,3PH,60HZ,D100Z,3632M,TEFC
Made To Order
No
Medium Description
Hydraulic Pump, 2.2 HP, 1800 RPM, Frame Size D100Z, SaePump Mounting, 3 Phase, 460 V, 60 Hz (36Q745N013G1)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
D100Z
Mounting Orientation
Horizontal
Mounting Position
B34
NEMA Design Code
B
Number of Phases
3
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
2.20 kW
Power Factor
78 %
Product Name
Hydraulic Pump
Product Net Depth / Length
19.375 in
Product Net Height
13.123 in
Product Net Weight
73 lb
Product Net Width
13.75 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.1 A
Rated Efficiency
89.50 %
Rated Speed
1755 r/min
Selling Unit of Measure
piece
Service Factor
1.15
Short Description
2.2 HP, 1800 RPM, Frame Size D100Z, SaePump, 3 PH, 460 V
Standards
NEMA
Starting of Motor
Wye Start - Delta Run
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
460 V
Feature → Business Impact → Application: The 2.20 kW rating at 460 V 3-phase 60 Hz delivers high power density, enabling faster hydraulic actuation and reduced cycle times in presses and tooling. This translates to measurable throughput gains on machining lines and bottleneck relief in loader/assembler stations. Application: suitable for heavy hydraulic actuation in process automation with compact equipment footprints. Feature → Business Impact → Application: TEFC enclosure provides rugged protection against dust, moisture, and grime, reducing unexpected downtime and maintenance costs in dusty plant floors. Application: ideal for outdoor or semi-enclosed installations in metalworking or packaging lines. Feature → Business Impact → Application: Frame D100Z with SaePump mounting ensures standardizable footprints and easy retrofit with existing Baldor-like drives, minimizing installation risk. Application: upgrades to legacy hydraulic units or swaps during plant modernization projects. Feature → Business Impact → Application: Premium Efficiency rating lowers energy consumption by aligning with energy codes and utility incentives, improving total cost of ownership. Application: continuous duty operations in conveyors and machine tools. Feature → Business Impact → Application: Service Factor 1.15 and 4-pole design provide reliable torque delivery and smoother startups, reducing mechanical stress and extending bearing life. Application: high-load hydraulic manifolds and clamping systems. Feature → Business Impact → Application: 60 Hz operation with 1755 r/min synchronous speed supports precise control in synchronized automation routines. Application: CNC and automation cells requiring predictable pump performance. The combination of 3-phase power, TEFC protection, and robust mounting options also supports straightforward installation and long-term maintenance planning.
