ABB 7B36S23W501 5HP Motor - CSA UR
Part Number: 7B36S23W501
Quick Summary
ABB 7B36S23W501 5HP motor is a general purpose HVAC solution designed for 1-phase, 230V operation in fans, blowers, and air handling equipment. It helps maintenance teams reduce downtime with a readily available, standard footprint motor built for HVAC environments. If you’re battling supply delays or mismatched frame sizes, this model delivers consistent performance and easy interchangeability. The motor carries key certifications including CSA and UR for North American compliance, along with NEMA standards in the design. With TEAO enclosure, horizontal foot mounting, and a compact 184T frame, it provides reliable cooling and straightforward installation. In practice, you’ll gain predictable life-cycle costs and smoother project timelines when replacing aged motors in HVAC systems.
Product Information
Extended Description
7B36S23W501 ABB: General Purpose HVAC 5 Hp 230 V (36S23W501)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,3450RPM,1PH,60HZ,184T,3646LC,TE
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
36S23W501
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
Standard
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEAO
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
36S23W501
Gross Volume
5274.135 in³
Gross Weight
92 lb
Insulation Class
B
Invoice Description
5HP,3450RPM,1PH,60HZ,184T,3646LC,TEAO,F1
Made To Order
No
Medium Description
General Purpose HVAC, 5 HP, 3600 RPM, Frame Size 184T, Standard Mounting, 1 Phase, 230 V, 60 Hz (36S23W501)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
184T
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
L
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
96 %
Product Name
General Purpose HVAC
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
92 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
21 A
Rated Efficiency
84 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
1.13 in
Short Description
5 HP, 3600 RPM, Frame Size 184T, Standard, 1 PH, 230 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
Voltage Rating
230 V
Feature → Business Impact → Application: The 5 HP, 3450 r/min, 1-phase, 230 V design aligns with common HVAC fan and blower requirements, delivering sufficient torque and speed for belt-driven arrangements. This translates to improved system balance and reduced vibration, which lowers maintenance cycles in air handling units. Application: Suitable for general purpose HVAC fans, air handlers, and small process fans, particularly in spaces with limited electrical infrastructure. Feature → Business Impact → Application: The TEAO enclosure with foot-mounted, horizontal mounting simplifies installation and reduces protective housing costs, enabling quick retrofits and easier maintenance in retrofit projects. Application: Ideal for retrofit of legacy 184T frame motors in commercial buildings and light industrial HVAC equipment. Feature → Business Impact → Application: Efficiency rated at 84% and a Rated Current of 21 A support energy-conscious selection, offering measurable operating cost savings over lifetime service and lower heat load in equipment housings. Application: Long-running fans and blowers in climate control systems, reducing electrical bill impact. Feature → Business Impact → Application: Direct-on-line starting capability and 60 Hz operation provide straightforward control logic and compatibility with standard building power, reducing soft-start requirements and drive costs. Application: HVAC systems with simple starter arrangements or limited DC bus options. Feature → Business Impact → Application: Frame 184T and 1.13 in shaft diameter ensure compatibility with common drive pulleys, couplings, and bases, minimizing modification needs. Application: New installations or replacements in standard 184T footprint machinery. Feature → Business Impact → Application: Stocked at multiple warehouses with 0-day lead times supports fast project execution and reduces downtime during capital projects. Application: Large-scale HVAC retrofits or new builds where supply chain speed is critical. Industry insight: In HVAC motor procurement, matching frame, mounting, and enclosure reduces commissioning risk, lowers spare parts inventory, and improves serviceability for service technicians.
