ABB 7B36T314S042G1 Motor - 5HP TEFC Premium Efficiency
Part Number: 7B36T314S042G1
Quick Summary
Pump Motor ABB 7B36T314S042G1 delivers dependable 5 HP, 230 V performance for jet pumps and process-flow applications. Engineers frequently confront downtime and higher energy costs when selecting mismatched motors for 3-phase systems. This model carries NEMA Premium Efficiency, CSA EEV, and UR listings, ensuring energy savings, safety, and global compliance. A rugged TEFC enclosure and the 56J frame support long service life in demanding environments, while dual-voltage 230/460 V compatibility simplifies procurement and installation. With fast stock availability and standard mounting options, this motor translates into lower total cost of ownership for industrial pumping systems and related equipment.
Product Information
Extended Description
7B36T314S042G1 ABB: Pump Motor 5 Hp 230 V (36T314S042G1)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
5HP,3450RPM,3PH,60HZ,56J,3630M,TEFC
Ambient Temperature
40 °C
Bearing
6206, Ball
Bearing NDE
6205
Brake Present
No
Brand / Label
Baldor-Reliance®
Catalog Number
36T314S042G1
Certification Agency
CSA EEV | NEMA_PREMIUM | UR
Country of Origin
United States (US)
Customs Tariff Number
85015220
Drive End Flange Type
C-Face
Efficiency Level
Premium Efficiency (NEMA 12-12)
Electrical Data
Enclosure Type
TEFC
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
36T314S042G1
Gross Volume
5274.135 in³
Gross Weight
74 lb
Insulation Class
F
Invoice Description
5HP,3450RPM,3PH,60HZ,56J,3630M,TEFC,W6,N
Made To Order
No
Maximum Speed
6000 r/min
Medium Description
56J Jet Pump, 5 HP, 3600 RPM, Frame Size 56J, C-Face Mounting, 3 Phase, 208-230/460 V, 60 Hz (36T314S042G1)
Minimum Order Quantity
1 piece
Motor Base Type
Footless
Motor Frame Size
56J
Mounting Orientation
Vertical
Mounting Position
W6
NEMA Design Code
A
Number of Phases
3
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
5 Hp
Power Factor
93 %
Product Name
56J Jet Pump
Product Net Depth / Length
21.625 in
Product Net Height
15.125 in
Product Net Weight
74 lb
Product Net Width
16.125 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
12.8 A | 11.4 A | 5.7 A
Rated Efficiency
88.50 %
Rated Speed
3450 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.63 in
Shaft Grounding
Shaft Grounding
Short Description
5 HP, 3600 RPM, Frame Size 56J, C-Face, 3 PH, 208-230/460 V
Standards
NEMA
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
Voltage Rating
230 V | 460 V
Premium efficiency and high power factor deliver lower energy costs and reduced cooling requirements, especially in continuous pump duty, translating to noticeable operating savings in water treatment and process-flow lines. The TEFC enclosure and steel 56J frame provide robust protection in dirty or humid environments, enabling longer intervals between maintenance and easier replacement during plant upgrades. Dual voltage capability (230/460 V) and 60 Hz compatibility simplify integration with existing plant electrical distribution, reducing transformer needs and enabling straightforward, direct-on-line (DOL) starting. A 2-pole design with 3450 r/min nominal speed and 3600 r/min synchronous speed supports quick pump acceleration while maintaining reliable torque characteristics for jet and centrifugal pumps. Mounting versatility (C-face flange, vertical/W6 orientation) and a shaft diameter of 0.63 in ease installation and alignment with standard pump adaptors while supporting industry replacements. Industry-standard features such as NEMA Design A, 56J frame, and 14-12 AWG bearing configurations address common OEM and service requirements, reducing retrofit risk and ensuring long-term operability.
