ABB 7B812RE Motor - 1PH 60Hz TENV Enclosure CSA Certified
Part Number: 7B812RE
Quick Summary
ABB 7B812RE Motor provides dependable 0.75 HP, single-phase drive for compact machines in manufacturing and workshop environments. This motor helps prevent downtime caused by voltage mismatches, overheating, and enclosure exposure in small-line equipment. It carries CSA certification and is designed with a TENV enclosure, a steel frame, and a 40 °C ambient rating for harsher shop floors. The dual voltage 115/230 V capability and direct-on-line starting simplify electrical design and startup sequencing, reducing panel complexity. With its horizontal foot mounting and compact footprint, installation is straightforward on grinders, buffers, lathes, and belt sanders, delivering predictable performance and lower life-cycle costs for maintenance teams and procurement teams alike.
Product Information
Extended Description
7B812RE ABB: .75HP,3600RPM,1PH,60HZ,3524C,GRND
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.75HP,3600RPM,1PH,60HZ,3524C,GRND
Ambient Temperature
40 °C
Brand / Label
Baldor-Reliance®
Catalog Number
812RE
Certification Agency
CSA
Country of Origin
United States (US)
Customs Tariff Number
8460908020
Dimension Diagram
G8LY0212: Dimension Sheet
Drive End Flange Type
Standard
ETIM 7
EC001851 - Electric motor
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TENV
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
812RE
Gross Volume
7192.91 in³
Gross Weight
96 lb
Horsepower Rating UL/CSA
0.750 Hp
IDEA Granular Category Code (IGCC)
1329 >> Single phase motor AC
Insulation Class
B
Invoice Description
.75HP,3600RPM,1PH,60HZ,3524C,GRND
Made To Order
No
Medium Description
1 Phase, TENV Enclosure, (812RE)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Mounting Orientation
Horizontal
Number of Phases
1
Number of Poles
2P
Number of Poles (High)
2
Number of Speeds
single_speed
Order Multiple
1 piece
Output Power
0.75 Hp
Product Name
Grinders/Buffers/Lathes/Belt Sander
Product Net Depth / Length
26.625 in
Product Net Height
16.25 in
Product Net Weight
96 lb
Product Net Width
16.625 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.8 A | 2.4 A
Rated Speed
3600 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Service Factor Percentage
1.00 %
Shaft Diameter
0.75 in
Short Description
1 PH, TENV,
Standards
Other
Starting of Motor
Direct on line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
3600 r/min
Type of Duty
Continuous
UNSPSC
26101116
Voltage Rating
115 V | 230 V
Feature: 0.75 HP, 3600 r/min, 1-phase, 60 Hz. Business Impact: Delivers compact, dependable power for small equipment, enabling consistent belt speeds and predictable process timing. Application: Grinders, buffers, lathes, and belt sanders benefit from a stable, single-phase motor with straightforward wiring. Feature: Dual voltage 115/230 V. Business Impact: Reduces electrical design complexity and stock variety, streamlining procurement. Application: Easy integration into US and mixed-voltage facilities. Feature: TENV enclosure with steel frame. Business Impact: Enhanced protection in dirty, moderate-temperature environments, improving uptime and service intervals. Application: Shop floors and manufacturing cells with limited climate control. Feature: Direct-on-Line starting. Business Impact: Minimizes start-up components and panel wiring, lowering installation time and potential fault points. Application: Fast, reliable line starts for intermittent operations. Feature: Foot-mounted, horizontal orientation; 96 lb weight. Business Impact: Simple, room-friendly installation with stable mechanical alignment and reduced mounting effort. Application: Bench-top to compact production lines. Feature: Insulation Class B; Shaft Ø 0.75 in; 2P, 3600 r/min. Business Impact: Durable insulation and robust shaft support reduce heat-related wear and extend motor life. Application: High-cycle applications where reliability matters. This portfolio of features aligns with Baldor-Reliance design practices, supports 115/230 V controls, and enables streamlined maintenance planning and cost savings over the equipment lifecycle.
Get a Quick Quote for a ABB 7B812RE
Chat with us on WhatsApp - fast responses guaranteed
Need to speak with someone? We'll call you back within 2 hours during business hours
Interested in ABB 7B812RE?
Enquire Now
FAQs
The 7B812RE supports dual voltage (115/230 V) operation for single-phase systems. Wire the motor per the included connection diagram for your selected voltage: use the appropriate L/N connections, connect the ground, and configure the overload protection accordingly. The Direct-on-Line starting reduces panel components, allowing a compact starter configuration and simplified commissioning in 60 Hz control schemes.
This motor uses Direct-on-Line starting, suitable for straightforward, high-inrush starts without soft-start options. It is a 2-pole design with a rated speed of 3600 r/min at 60 Hz, delivering consistent torque for short-cycle and continuous-duty applications. The insulation class B provides reliable insulation up to typical shop temperatures with moderate ambient exposure.
Yes. The 7B812RE is explicitly compatible with light industrial machines like grinders, buffers, lathes, and belt sanders. Its 0.75 HP rating, 3600 r/min speed, and 2-pole configuration support smooth belt-driven or grinding setups. The horizontal foot mounting and dual-voltage capability simplify integration into existing mechanical and electrical layouts while maintaining reliable performance under continuous operation.
The motor carries CSA certification, reflecting compliance with North American safety standards. It features a TENV (Totally Enclosed, Non-Ventilated) enclosure appropriate for typical shop environments, an insulation class B rating, and a 40 °C ambient temperature rating. This combination ensures dependable performance under common industrial conditions and safer operation in protected enclosures.
The 7B812RE offers straightforward maintenance with a robust steel frame, direct-on-line start, and a compact, easily mounted footprint. Its 96 lb mass supports stable operation in horizontal orientations, reducing vibration and wear. Dual-voltage versatility minimizes spare-part investments, while CSA certification supports compliance-driven procurement, contributing to lower total cost of ownership over the motor’s lifecycle.
