ABB AFL3504A General Purpose HVAC Motor - 1PH, TEAO, NEMA N
Part Number: 7BAFL3504A
Quick Summary
ABB AFL3504A is a general purpose HVAC motor for standard 1-phase drives in commercial HVAC equipment. Engineers often contend with downtime and energy waste when a motor isn’t matched to load, causing sluggish start-up and higher maintenance. This model meets CSA | UR recognition and NEMA Design Code N, with a TEAO enclosure for clean integration and reliable cooling. Operating at 115/230 V, 60 Hz, it delivers 0.5 HP at 1745 rpm in a compact 56 frame footprint. Ready-stock and straightforward installation help shorten procurement cycles and reduce total cost of ownership. Its 1-phase, direct-on-line start and standard foot mounting simplify field wiring and retrofits.
Product Information
Extended Description
7BAFL3504A ABB: General Purpose HVAC 0.5 Hp 115 V (AFL3504A)
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
EGAUT001EXPU
Warranty Return
Product under warranty must be returned
Configuration Only
No
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
GBINS001EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
SGIND004EXPU
Warranty Return
Product under warranty must be returned
Country of Origin
United States (US)
Lead Time
0 day
Made To Order
No
Product Sales Status
Active
Quote Only
No
Stocked At Warehouses
USABB014EXPU
Warranty Return
Product under warranty must be returned
ABB Type Designation
.5HP,1745RPM,1PH,60HZ,56,3424LC,TEA
Ambient Temperature
40 °C
Bearing
6203, Ball
Bearing NDE
6203
Brake Present
No
Brand / Label
Baldor-Reliance
Catalog Number
AFL3504A
Certification Agency
CSA | UR
Country of Origin
United States (US)
Customs Tariff Number
85013100
Drive End Flange Type
Standard
Efficiency Level
Not Regulated / Exempt
Electrical Data
Enclosure Type
TEAO
Frame Material
Steel
Frame Size
Undefined
Frequency (f)
60 Hz
Global Commercial Alias
AFL3504A
Gross Volume
2110.969 in³
Gross Weight
32 lb
Insulation Class
F
Invoice Description
.5HP,1745RPM,1PH,60HZ,56,3424LC,TEAO,F1
Made To Order
No
Medium Description
General Purpose HVAC, 0.5 HP, 1800 RPM, Frame Size 56, Standard Mounting, 1 Phase, TEAO Enclosure, 115/230 V, 60 Hz (AFL3504A)
Minimum Order Quantity
1 piece
Motor Base Type
Foot Mounted
Motor Frame Size
56
Mounting Orientation
Horizontal
Mounting Position
F1
NEMA Design Code
N
Number of Phases
1
Number of Poles
4P
Number of Poles (High)
4
Number of Speeds
Single Speed
Order Multiple
1 piece
Output Power
0.5 Hp
Power Factor
89 %
Product Name
General Purpose HVAC
Product Net Depth / Length
16.5 in
Product Net Height
11.125 in
Product Net Weight
32 lb
Product Net Width
11.5 in
Product Type
Undefined
Quote Only
No
Rated Current (In)
4.6 A | 2.3 A
Rated Efficiency
78.50 %
Rated Speed
1745 r/min
Selling Unit of Measure
piece
Service Factor
1.00
Shaft Diameter
0.63 in
Short Description
0.5 HP, 1800 RPM, Frame Size 56, Standard, 1 PH, TEAO, 115/230 V
Standards
NEMA
Starting of Motor
Direct On Line
Stocked At (Warehouses)
China | Alabama, United States | Alaska, United States
Synchronous Speed (vsyn)
1800 r/min
Type of Duty
Continuous
Voltage Rating
115 V | 230 V
Feature → Business Impact → Application: The AFL3504A delivers 0.5 HP at 1745 rpm in a compact 56 frame, enabling reliable torque for small fans and blowers while reducing energy waste and downtime in commercial HVAC systems. This translates to lower operating costs and improved system performance in packaged units and retrofits. Feature → Business Impact → Application: TEAO enclosure with dual voltage 115/230 V supports easier installation across global sites, eliminating unnecessary power conversion steps and speeding up commissioning for HVAC equipment in warehouses and production facilities. Feature → Business Impact → Application: 60 Hz, 1-phase operation with direct-on-line starting reduces startup current spikes and wiring complexity, delivering faster demand response and simpler maintenance in cooling towers, air handlers, and compact air-processing units. Feature → Business Impact → Application: NEMA Design N and CSA | UR certifications provide regulatory confidence, enabling safer procurement and ongoing compliance for industrial facilities and service contracts. Feature → Business Impact → Application: Foot mounted, 56 frame, 0.63 in shaft, and bearing 6203 offer a robust, serviceable package that fits standard footprints and simplifies alignment, replacement, and spares management for equipment upgrades. Feature → Business Impact → Application: Stocked at multiple warehouses with 0 day lead time supports rapid deployment, minimizing downtime and accelerating project timelines for capital projects and service calls.
